Parameter Descriptions
13-52 SL Controller Action
Option: Function:
[29] Start timer 0 Starts timer 0, see
parameter 13-20 SL Controller Timer
for further description.
[30] Start timer 1 Starts timer 1, see
parameter 13-20 SL Controller Timer
for further description.
[31] Start timer 2 Starts timer 2, see
parameter 13-20 SL Controller Timer
for further description.
[32] Set digital out Any output with smart logic output
A low A is low.
[33] Set digital out Any output with smart logic output
B low B is low.
[34] Set digital out Any output with smart logic output
C low C is low.
[35] Set digital out Any output with smart logic output
D low D is low.
[36] Set digital out Any output with smart logic output
E low E is low.
[37] Set digital out Any output with smart logic output
F low F is low.
[38] Set digital out Any output with smart logic output
A high A is high.
[39] Set digital out Any output with smart logic output
B high B is high.
[40] Set digital out Any output with smart logic output
C high C is high.
[41] Set digital out Any output with smart logic output
D high D is high.
[42] Set digital out Any output with smart logic output
E high E is high.
[43] Set digital out Any output with smart logic output
F high F is high.
[60] Reset Counter Resets counter A to 0.
A
[61] Reset Counter Resets counter B to 0.
B
[70] Start timer 3 Starts timer 3, see
parameter 13-20 SL Controller Timer
for further description.
[71] Start timer 4 Starts timer 4, see
parameter 13-20 SL Controller Timer
for further description.
[72] Start timer 5 Starts timer 5, see
parameter 13-20 SL Controller Timer
for further description.
MG06J202
Programming Guide
13-52 SL Controller Action
Option:
[73]
[74]
[80]

4.13 Parameters: 14-** Special Functions

14-00 Switching Pattern
Option:
[0]
[1]
*
14-01 Switching Frequency
Select the frequency converter switching frequency. Changing
the switching frequency reduces acoustic noise from the motor.
Default values depend on power size.
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
Danfoss A/S © 03/2019 All rights reserved.
Function:
Start timer 6 Starts timer 6, see
parameter 13-20 SL Controller Timer
for further description.
Start timer 7 Starts timer 7, see
parameter 13-20 SL Controller Timer
for further description.
Sleep Mode
Function:
Select the switching pattern: 60°
AVM or SFAVM.
NOTICE
The frequency converter may
adjust the switching pattern
automatically to avoid a trip.
60 AVM
SFAVM
Function:
NOTICE
The output frequency value of
the frequency converter must
never exceed 10% of the
switching frequency. When the
motor is running, adjust the
switching frequency in
parameter 14-01 Switching
Frequency to minimize motor
noise.
NOTICE
To avoid a trip, the frequency
converter can adjust the
switching frequency automat-
ically.
1.0 kHz
1.5 kHz
2.0 kHz
2.5 kHz
3.0 kHz
3.5 kHz
4.0 kHz
5.0 kHz
4 4
