Parameter Descriptions
5-40 Function Relay
Option:
[40] Out of ref
range
4 4
[41] Below
reference, low
[42] Above ref,
high
[43] Extended PID
Limit
[45] Bus ctrl.
[46] Bus ctrl, 1 if
timeout
[47] Bus ctrl, 0 if
timeout
[59] Remote,enable
,no TW
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
74
VLT® AutomationDrive FC 361
Function:
to prepare switching the frequency
converter in open loop in an
emergency case.
Active when the actual speed is
outside settings in
parameter 4-52 Warning Speed Low
to parameter 4-55 Warning Reference
High.
Active when actual speed is below
speed reference setting.
Active when actual speed is above
speed reference setting.
Controls digital output/relay via
bus. The state of the output is set
in parameter 5-90 Digital & Relay Bus
Control. The output state is retained
in the event of a bus timeout.
Controls output via bus. The state
of the output is set in
parameter 5-90 Digital & Relay Bus
Control. If a bus timeout occurs, the
output state is set high (on).
Controls output via bus. The state
of the output is set in
parameter 5-90 Digital & Relay Bus
Control. If a bus timeout occurs, the
output state is set low (Off).
See parameter group 13-1*
Comparators. If comparator 0 in SLC
is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1*
Comparators. If comparator 1 in SLC
is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1*
Comparators. If comparator 2 in SLC
is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1*
Comparators. If comparator 3 in SLC
is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1*
Comparators. If comparator 4 in SLC
Danfoss A/S © 03/2019 All rights reserved.
5-40 Function Relay
Option: Function:
is true, the output goes high.
Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1*
Comparators. If comparator 5 in SLC
is true, the output goes high.
Otherwise, it is low.
[70] Logic rule 0 See parameter group 13-4* Smart
Logic Control. If logic rule 0 in SLC is
true, the output goes high.
Otherwise, it is low.
[71] Logic rule 1 See parameter group 13-4* Smart
Logic Control. If logic rule 1 in SLC is
true, the output goes high.
Otherwise, it is low.
[72] Logic rule 2 See parameter group 13-4* Smart
Logic Control. If logic rule 2 in SLC is
true, the output goes high.
Otherwise, it is low.
[73] Logic rule 3 See parameter group 13-4* Smart
Logic Control. If logic rule 3 in SLC is
true, the output goes high.
Otherwise, it is low.
[74] Logic rule 4 See parameter group 13-4* Smart
Logic Control. If logic rule 4 in SLC is
true, the output goes high.
Otherwise, it is low.
[75] Logic rule 5 See parameter group 13-4* Smart
Logic Control. If logic rule 5 in SLC is
true, the output goes high.
Otherwise, it is low.
[80] SL digital See parameter 13-52 SL Controller
output A Action. Output A is low on smart
logic action [32]. Output A is high
on smart logic action [38].
[81] SL digital See parameter 13-52 SL Controller
output B Action. Output B is low on smart
logic action [33]. Output B is high
on smart logic action [39].
[82] SL digital See parameter 13-52 SL Controller
output C Action. Output C is low on smart
logic action [34]. Output C is high
on smart logic action [40].
[83] SL digital See parameter 13-52 SL Controller
output D Action. Output D is low on smart
logic action [35]. Output D is high
on smart logic action [41].
[84] SL digital See parameter 13-52 SL Controller
output E Action. Output E is low on smart
logic action [36]. Output E is high
on smart logic action [42].
