Danfoss VLT AutomationDrive FC 361 Programming Manual page 74

Parameter Descriptions
4 4
[121] Remote
reference
active
[122] No alarm
[123] Start
command
active
[124] Running
reverse
[125] Drive in hand
mode
[126] Drive in Auto
mode
[189] External fan
control
[193] Sleep Mode
[194] Broken Belt
[221] IGBT-cooling
5-30 Terminal 27 Digital Output
Option:
[0] No operation Functions are described in parameter group
*
72
VLT® AutomationDrive FC 361
Reference site set Local
in reference
parameter 3-13 R active
eference Site [120]
Hand 1
Hand⇒off 1
Auto⇒off 0
Auto 0
Table 4.12 Local Reference Active
Output is high when
parameter 3-13 Reference Site = [1] Remote
or [0] Linked to hand/auto while the LCP is
in auto-on mode. See Table 4.12.
Output is high when no alarm is present.
Output is high when there is an active
start command (that is via digital input bus
connection, hand-on, or auto-on), and no
stop or start command is active.
Output is high when the frequency
converter runs counterclockwise (the
logical product of the status bits running
AND reverse).
Output is high when the frequency
converter is in hand-on mode (as indicated
by the LED light above [Hand On]).
Output is high when the frequency
converter is in auto-on mode (as indicated
by the LED light above [Auto On]).
The internal logics for the internal fan
control is transferred to this output to
make it possible to control an external fan
(relevant for hp duct cooling).
The frequency converter/system has turned
into sleep mode. See parameter group
22-4* Sleep Mode.
A broken belt condition has been
detected. This function must be enabled in
parameter 22-60 Broken Belt Function.
Use this option for handling the
overcurrent trips. When the frequency
converter detects an overcurrent condition,
it shows alarm 13, Overcurrent and triggers
a reset. If the overcurrent condition occurs
rd
the 3 time in a row, the frequency
converter shows alarm 13, Overcurrent and
initiates a 3-minute delay before the next
reset.
Function:
5-3* Digital Outputs.
Danfoss A/S © 03/2019 All rights reserved.
Remote
5-31 Terminal 29 Digital Output
reference
Option:
active
[0] No operation Functions are described in parameter group
*
[121]
0
5-32 Term X30/6 Digi Out (MCB 101)
0
0
Option:
1
[0] No operation Functions are described in parameter group
*
5-33 Term X30/7 Digi Out (MCB 101)
Option:
[0] No operation Functions are described in parameter group
*
4.6.3 5-4* Relays
Parameters for configuring the timing and the output
functions for the relays.
5-40 Function Relay
Option:
[0] No operation
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem
ctrl
[4] Enable / no
warning
[5] Running
[6] Running / no
warning
Function:
5-3* Digital Outputs.
Function:
5-3* Digital Outputs.
Function:
5-3* Digital Outputs.
Function:
Relay 1 [0], Relay 2 [1].
®
VLT Extended Relay Card MCB 113:
Relay 3 [2], Relay 4 [3], Relay 5 [4],
Relay 6 [5].
®
VLT Relay Card MCB 105: Relay 7
[6], Relay 8 [7], Relay 9 [8].
All digital and relay outputs are by
default set to No Operation.
The control card is ready, for
example: Feedback from a
frequency converter where the
control is supplied by an external
®
24 V supply (VLT 24 V DC Supply
MCB 107) and the main power to
frequency converter is not detected.
The frequency converter is ready to
operate. Mains and control supplies
are OK.
The frequency converter is ready for
operation and is in auto-on mode.
Ready for operation. No start or
stop commands have been applied
(start/disable). No warnings are
active.
The motor is running, and shaft
torque is present.
Output speed is higher than the
speed set in parameter 1-81 Min
Speed for Function at Stop [RPM].
The motor runs and there are no
warnings.
MG06J202
