Parameter Descriptions
8-14 Configurable Control Word CTW
This is an array parameter with 16 elements, 1 element for each
bit in range 0–15. Each of the bits can be configured to any of
the following options.
Option:
[0]
None
4
4
[1]
Profile default
*
[2]
CTW Valid,
active low
[4]
PID error
inverse
[5]
PID reset I part Resets the I-part of the process PID
[6]
PID enable
[7]
External
Interlock
[66] Sleep Mode
8-19 Product Code
Range:
Size
related
2147483647]
*
4.9.3 8-3* FC Port Settings
8-30 Protocol
Option:
[0]
FC
*
[1]
FC MC
[2]
Modbus RTU
96
Function:
This parameter is not valid in software
versions before 4.93.
The frequency converter ignores the
information in this bit.
The functionality of the bit depends on
the selection in parameter 8-10 Control
Word Profile.
If set to 1, the frequency converter ignores
the remaining bits of the control word.
Inverts the resulting error from the process
PID controller. Available only if
parameter 1-00 Configuration Mode is set to
[7] Extended PID Speed OL.
controller. Equivalent to
parameter 7-40 Process PID I-part Reset.
Available only if parameter 1-00 Configu-
ration Mode is set to [7] Extended PID
Speed OL.
Enables the extended process PID
controller. Equivalent to
parameter 7-50 Process PID Extended PID.
Available only if parameter 1-00 Configu-
ration Mode is set to [7] Extended PID
Speed OL.
Function:
[0 -
Select 0 to read out the actual
fieldbus product code according to
the mounted fieldbus option. Select
1 to read out the actual vendor ID.
Function:
Select the protocol to be used. Changing
protocol is not effective until after powering
off the frequency converter.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
8-31 Address
Range:
1
*
8-32 FC Port Baud Rate
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
8-33 Parity / Stop Bits
Option:
[0]
*
[1]
[2]
[3]
8-34 Estimated cycle time
Range:
0 ms
*
8-35 Minimum Response Delay
Range:
10 ms
*
Function:
[ 1 - 247 ]
Enter the address for the frequency
converter (standard) port.
Valid range: Depends on selected
protocol.
Function:
2400 Baud
Baud rate selection for the FC
(standard) port.
4800 Baud
9600 Baud
19200 Baud
38400 Baud
57600 Baud
76800 Baud
115200 Baud
Function:
Even Parity, 1
Stop Bit
Odd Parity, 1
Stop Bit
No Parity, 1
Stop Bit
No Parity, 2
Stop Bits
Function:
[0 - 1000000
In noisy environments, the interface
ms]
may be blocked due to overload or
bad frames. This parameter specifies
the time between 2 consecutive
frames on the network. If the
interface does not detect valid
frames in that time, it flushes the
receive buffer.
Function:
[ 1 - 10000
Specify the minimum delay time
ms]
between receiving a request and
transmitting a response. This is
used for overcoming modem
turnaround delays.
MG06J202
