Parameter Descriptions
13-10 Comparator Operand
Option:
[3] Motor speed
[4] Motor Current
[5] Motor torque
[6] Motor power
4 4
[7] Motor voltage
[8] DC-link
voltage
[9] Motor Thermal Value is in percent.
[10] Drive thermal
[11] Heat sink
temp.
[12] Analog input
AI53
[13] Analog input
AI54
[14] Analog input
AIFB10
[15] Analog input
AIS24V
[17] Analog input
AICCT
[18] Pulse input
FI29
[19] Pulse input
FI33
[20] Alarm number The number of registered alarms.
[21] Warning
number
[22] Analog input
x30 11
[23] Analog input
x30 12
[30] Counter A
[31] Counter B
13-11 Comparator Operator
Option:
[0] <
120
VLT® AutomationDrive FC 361
Function:
[RPM] or [Hz], as set in
parameter 0-02 Motor Speed Unit.
Value is in percent.
Value is in percent.
Value is in percent.
Value is in percent.
AIFB10 is internal 10 V supply.
AIS24V is a 24 V switch mode
power supply.
Value is in [°]. AICCT is control card
temperature.
Value is in percent.
Value is in percent.
Function:
Select the operator to be used in
the comparison. This is an array
parameter containing comparator
operators 0–5.
The result of the evaluation is true
when the variable selected in
parameter 13-10 Comparator
Operand is smaller than the fixed
value in
parameter 13-12 Comparator Value.
The result is false if the variable
selected in
parameter 13-10 Comparator
Danfoss A/S © 03/2019 All rights reserved.
13-11 Comparator Operator
Option: Function:
Operand is greater than the fixed
value in
parameter 13-12 Comparator Value.
[1] ≈ (equal) The result of the evaluation is true
when the variable selected in
parameter 13-10 Comparator
Operand is approximately equal to
the fixed value in
parameter 13-12 Comparator Value.
[2] > Inverse logic of option [0] <.
[5] TRUE longer
than..
[6] FALSE longer
than..
[7] TRUE shorter
than..
[8] FALSE shorter
than..
13-12 Comparator Value
Array [6]
Range: Function:
Size [-100000 - Enter the trigger level for the
related 100000 ] variable that is monitored by this
*
comparator. This is an array
parameter containing comparator
values 0–5.
4.12.3 13-2* Timers
Use the result (true or false) from timers directly to define
an event (see parameter 13-51 SL Controller Event), or as
boolean input in a logic rule (see parameter 13-40 Logic
Rule Boolean 1, parameter 13-42 Logic Rule Boolean 2, or
parameter 13-44 Logic Rule Boolean 3). A timer is only false
when started by an action (for example [29] Start timer 1)
until the timer value entered in this parameter has elapsed.
Then it becomes true again.
All parameters in this parameter group are array
parameters with index 0–2. Select index 0 to program
timer 0, select index 1 to program timer 1, and so on.
13-20 SL Controller Timer
Range: Function:
Size [ 0 - 0] Enter the value to define the
related duration of the false output from
*
the programmed timer. A timer is
only false if it is started by an
action (that is [29] Start timer 1) and
until the given timer value has
elapsed.
