Parameter Lists
5.2.5 4-** Limits / Warnings
Param Parameter description
eter
numb
er
4-1* Motor Limits
4-10 Motor Speed Direction
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]
4-13 Motor Speed High Limit [RPM]
5 5
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit
4-19 Max Output Frequency
4-2* Limit Factors
4-20 Torque Limit Factor Source
4-21 Speed Limit Factor Source
4-3* Motor Fb Monitor
4-30 Motor Feedback Loss Function
4-31 Motor Feedback Speed Error
4-32 Motor Feedback Loss Timeout
4-4* Speed Monitor
4-40 Warning Freq. Low
4-41 Warning Freq. High
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-52 Warning Speed Low
4-53 Warning Speed High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
4-61 Bypass Speed From [Hz]
4-62 Bypass Speed To [RPM]
4-63 Bypass Speed To [Hz]
5.2.6 5-** Digital In/Out
Param Parameter description
eter
numb
er
5-0* Digital I/O mode
5-00 Digital I/O Mode
5-01 Terminal 27 Mode
5-02 Terminal 29 Mode
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
164
VLT® AutomationDrive FC 361
Default value
[2] Both directions
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
100 %
ExpressionLimit
ExpressionLimit
[0] No function
[0] No function
ExpressionLimit
300 RPM
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 A
ImaxVLT (P1637 (16.00)) A
ExpressionLimit
ExpressionLimit
-999999.999 N/A
999999.999 N/A
ExpressionLimit
ExpressionLimit
[2] Trip 1000 ms
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
Default value
[0] PNP
[0] Input
[0] Input
ExpressionLimit
