Parameter Descriptions
4.2.3 1-2* Motor Data
This parameter group contains input data from the
nameplate on the connected motor.
NOTICE
Changing the value of these parameters affects the
setting of other parameters.
NOTICE
The following parameters have no effect when
parameter 1-10 Motor Construction is set to [1] PM, non-
salient SPM:
•
Parameter 1-20 Motor Power [kW].
•
Parameter 1-22 Motor Voltage.
•
Parameter 1-23 Motor Frequency.
1-20 Motor Power [kW]
Range: Function:
NOTICE
Size [ 0.09 -
related 3000.00 kW]
*
This parameter cannot be
adjusted while the motor is
running.
Enter the nominal motor power in
kW according to the motor
nameplate data. The default value
corresponds to the nominal rated
output of the frequency converter.
1-22 Motor Voltage
Range: Function:
Size [ 10 - 1000 Enter the nominal motor voltage
related V] according to the motor nameplate
*
data. The default value corresponds
to the nominal rated output of the
unit.
1-23 Motor Frequency
Range: Function:
Size [20 - 1000 Select the motor frequency value
related Hz] from the motor nameplate data.
*
1-24 Motor Current
Range: Function:
Size [ 0.10 - Enter the nominal motor current
related 10000.00 A] value from the motor nameplate
*
data. The data is used for
calculating torque, motor overload
protection, and so on.
MG06J202
Programming Guide
1-25 Motor Nominal Speed
Range:
Size
related
*
1-26 Motor Cont. Rated Torque
Range:
Size
related
*
1-29 Automatic Motor Adaptation (AMA)
Option:
[0]
*
[1]
Danfoss A/S © 03/2019 All rights reserved.
Function:
[10 - 60000 Enter the nominal motor speed
RPM] value from the motor nameplate
data. The data is used for
calculating motor compensations.
n = n - n .
m,n s slip
Function:
[0.1 - Enter the value from the motor
100000.0 Nm] nameplate data. The default value
corresponds to the nominal rated
output. This parameter is available
when parameter 1-10 Motor
Construction is set to [1] PM, non-
salient SPM, that is the parameter is
valid for PM and non-salient SPM
motors only.
Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
The AMA function optimizes
dynamic motor performance by
automatically optimizing the
advanced motor parameters
(parameter 1-30 Stator Resistance
(Rs) to parameter 1-35 Main
Reactance (Xh)) at motor standstill.
Activate the AMA function by
pressing [Hand On] after selecting
[1] Enable Complete AMA or [2]
Enable Reduced AMA. See also the
section Automatic Motor Adaptation
in the design guide. After a normal
sequence, the display reads: Press
[OK] to finish AMA. After pressing
[OK], the frequency converter is
ready for operation.
NOTICE
Ensure that a value is set in
parameter 14-43 Motor Cosphi
before running AMA II.
Off
Enable Performs
Complete
AMA
4 4
