Parameter Descriptions
9-15 PCD Write Configuration
Array [10]
Option: Function:
[590] Digital & Relay
Bus Control
[593] Pulse Out #27
Bus Control
[595] Pulse Out #29
Bus Control
[597] Pulse Out
#X30/6 Bus
Control
[615] Terminal 53
High Ref./
Feedb. Value
[625] Terminal 54
High Ref./
Feedb. Value
[653] Term 42
Output Bus
Ctrl
[663] Terminal
X30/8 Bus
Control
[748] PCD Feed
Forward
[890] Bus Jog 1
Speed
[891] Bus Jog 2
Speed
[1680] Fieldbus CTW
1
[1682] Fieldbus REF 1
[1685] FC Port CTW 1
[1686] FC Port REF 1
9-16 PCD Read Configuration
Array [10]
Option: Function:
Select the parameters to be
assigned to PCD 3–10 of the
telegrams. The number of available
PCDs depends on the telegram
type. PCDs 3–10 contain the actual
data values of the selected
parameters. For standard PROFIBUS
telegram, see
parameter 9-22 Telegram Selection.
[0] None
[1500] Operating
hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
MG06J202
Programming Guide
9-16 PCD Read Configuration
Array [10]
Option:
[1601]
[1602]
[1603]
[1605]
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
[1616]
[1617]
[1618]
[1620]
[1621]
[1622]
[1624]
[1630]
[1634]
[1635]
[1638]
[1639]
[1645]
[1646]
[1647]
[1648]
[1650]
[1651]
[1652]
[1653]
[1657]
Danfoss A/S © 03/2019 All rights reserved.
Function:
Reference
[Unit]
Reference %
Status Word
Main Actual
Value [%]
Custom
Readout
Power [kW]
Power [hp]
Motor Voltage
Frequency
Motor current
Frequency [%]
Torque [Nm]
Speed [RPM]
Motor Thermal
Motor Angle
Torque [%]
High Res.
Torque [%]
Calibrated
Stator
Resistance
DC Link
Voltage
Heatsink
Temp.
Inverter
Thermal
SL Controller
State
Control Card
Temp.
Motor Phase U
Current
Motor Phase V
Current
Motor Phase
W Current
Speed Ref.
After Ramp
[RPM]
External
Reference
Pulse
Reference
Feedback[Unit]
Digi Pot
Reference
Feedback
[RPM]
