Parameter Descriptions
Feedback
Disturbed feedback signal
Lowpass lter
f = 10 Hz
g
Feedback
Filtered feedback signal
Illustration 4.34 Feedback Signal
MG06J202
Programming Guide
7-07 Speed PID Feedback Gear Ratio
Range:
1
*
0.6 t (Sec.)
Illustration 4.35 Speed PID Feedback Gear Ratio
7-08 Speed PID Feed Forward Factor
Range:
0 %
*
4.8.1 7-1* Torque PI Control
Parameters for configuring the torque PI control.
7-12 Torque PI Proportional Gain
Range:
100 %
0.6 t (Sec.)
7-13 Torque PI Integration Time
Range:
0.020 s
Danfoss A/S © 03/2019 All rights reserved.
Function:
[ 0.0001 - The frequency converter multiplies
32.0000] the speed feedback by this ratio.
Motor
Par 7-07=1.00
Function:
[0 - 500 %] The reference signal bypasses the
speed controller by the amount
specified. This feature increases the
dynamic performance of the speed
control loop.
Function:
[0 - 500 %] Enter the proportional gain value
*
for the torque controller. Selection
of a high value makes the
controller react faster. Too high a
setting leads to controller
instability.
Function:
[0.002 - 2 s] Enter the integration time for the
*
torque controller. Selection of a low
value makes the controller react
faster. Too low a setting leads to
controller instability.
4
n1 n2
Par 7-07=n1/n2
