Toyota Camry Manual page 507

AX–104
AUTOMATIC TRANSAXLE
S
If the maximum torque is exceeded while retightening the
nut, replace the bearing spacer and repeat the preload
procedure.
Do not back off the nut to reduce the preload.
Maximum torque: 353 N·m (3,600 kgf·cm, 260 ft·lbf)
(e) If the preload is adjusted within specification, make a note
of it.
(f) Stroke the lock nut.
6. INSTALL APPLY GASKET
7. PLACE OUTER RACE AND SHIM ONTO RH SIDE
BEARING
8. PLACE DIFFERENTIAL CASE INTO TRANSAXLE
CASE
Be sure to install the shim and outer race into place.
– COMPONENT PARTS INSTALLATION
If the preload is less then specified, retighten the nut
13 N·m (130 kgf·cm, 9 ft·lbf) at a time until the speci-
fied preload is reached.
