ENGINE IMMOBILISER SYSTEM
REGISTRATION PROCEDURE
1. KEY REGISTRATION IN AUTOMATIC REGISTRATION MODE
(a) Registration of a new transponder key.
HINT:
D
This must be done when you have installed a new ECM.
D
The new ECM is in the automatic key code registration mode. The already fixed number of key codes
for this ECM can be registered.
On this type of vehicle, up to 4 key codes can be registered.
D
In the automatic registration mode, the last key registered becomes sub–key.
Yes
BODY ELECTRICAL
START
Insert the key in the key cylinder.
Under registration
Registration completion
Remove the key.
Will you register the
next key?
No
END
– ENGINE IMMOBILISER SYSTEM
Author :
BE–119
Security indicator blinks until the first
key is inserted. The indicator lights up
after the key registration.
Security Indicator ON
Security Indicator
OFF
Security Indicator ON
(After the last key (sub–key)
has been registered, the indi-
cator goes off.)
