Toyota Camry Manual page 741

BE–40
w/o Timer
Washer ON
w/ Timer
Washer ON
7
8
17
16
7
16
17
16
BODY ELECTRICAL
INSPECTION
OFF
1.
INT
LO
HI
OFF
INT
LO
HI
If continuity is not as specified, replace the switch.
2
11
N20218
2.
(a)
2
(b)
(c)
(d)
N20210
(e)
7
2
INT time control
switch position
FAST
N20211
SLOW
Non variable type
If operation is not as specified, replace the wiper and washer
switch.
– WIPER AND WASHER SYSTEM
INSPECT FRONT WIPER AND WASHER SWITCH
CONTINUITY
Switch position Tester connection
OFF
INT
LO
HI
Washer ON
INSPECT INTERMITTENT OPERATION
Turn the wiper switch to INT position.
Turn the intermittent time control switch to FAST position.
Connect the positive (+) lead from the battery to terminal
16 and the negative (–) lead to terminal 2.
Connect the positive (+) lead from the voltmeter to termi-
nal 7 and the negative (–) lead to terminal 2, check that
the meter needle indicates battery positive voltage.
After connecting terminal 16 to terminal 17, connect it to
terminal 2, check the voltage rises from 0 volts to battery
positive voltage within the time, as shown in the table.
Approx. 2 sec.
10.7 ± 5 sec.
3.3 ± 1 sec.
Author :
Specified condition
7 – 16 Continuity
7 – 16 Continuity
7 – 17 Continuity
8 – 17 Continuity
2 – 11 Continuity
Voltage
Battery positive voltage
0 V
Battery positive voltage
0 V
Battery positive voltage
0 V
Date :
BE0AH–03
2260
