AUTOMATIC TRANSAXLE
13. INSTALL RING GEAR INTO CASE
(a) Coat the races and bearing with petroleum jelly and install
them onto the ring gear.
Bearing and races
mm (in.)
Front Race
Bearing
Rear Race
(b) Install the ring gear into the case.
14. INSTALL REAR PLANETARY GEAR INTO CASE
(a) Align the flukes of the discs in the first and reverse brake.
(b) Coat the thrust washer with petroleum jelly.
Align the tab of the washer with the hollow of the carrier.
(c) Align the spline of the planetary carrier with either of the
flukes of the discs, and install the planetary gear into the
first and reverse brake discs.
15. INSTALL NO.2 ONE–WAY CLUTCH INTO CASE WITH
SHINY SIDE UPWARD
(a) Place the one–way clutch with the shiny side upward.
(b) Install the one–way clutch onto the inner race while turn-
ing the planetary gear clockwise with SST.
SST 09350–32014 (09351–32050)
– COMPONENT PARTS INSTALLATION
Outer Diameter
37.3 (1.469)
37.6 (1.480)
37.6 (1.480)
AX–111
Inner Diameter
24.1 (0.949)
24.0 (0.945)
22.2 (0.874)
