Toyota Camry Manual page 344

AX–104
AUTOMATIC TRANSAXLE
S
S
If the maximum torque is exceeded while retightening the
nut, replace the bearing spacer and repeat the preload
procedure.
Do not back off the nut to reduce the preload.
Maximum torque:
(e) If the preload is adjusted within specification, make a note
of it.
DIFFERENTIAL INSTALLATION
1. PLACE OUTER RACE AND SELECTED ADJUSTING
SHIM ONTO RH SIDE BEARING
2. PLACE DIFFERENTIAL CASE INTO CASE
Be sure to install the adjusting shim into place.
3. INSTALL LH BEARING RETAINER
(a) Install a new O–ring.
(b) Position the retainer by tapping it while holding the differ-
ential case center with the retainer.
(c) Clean the threads of the bolts and case with white gaso-
line.
– COMPONENT PARTS INSTALLATION
If the preload is greater than specified, replace the
bearing spacer.
If the preload is less than specified, retighten the nut
13 N·m (130 kgf·cm, 9 ft·lbf) at a time until the speci-
fied preload is reached.
289 N·m (2,950 kgf·cm, 213 ft·lbf)
AX0SX–01
