AX–92
AUTOMATIC TRANSAXLE
2. INSTALL BEARING OUTER RACE TO LH SIDE BEAR-
ING RETAINER
(a) Place the shim onto the retainer.
(b) Using SST, press a new outer race into the retainer.
SST 09350–32014 (09351–32111, 09351–32130)
HINT: Use the 2.60 mm (0.1024 in.) thick thim.
3. INSTALL LH OIL SEAL
(a) Using SST, drive in a new oil seal.
SST 09350–32014 (09351–32130, 09351–32150)
Oil seal drive in depth:
(b) Coat the oil seal lip with MP grease.
4. ASSEMBLE DIFFERENTIAL CASE
(a) Install the removed thrust washers to the side gears.
(b) Install the side gears with thrust washers, pinion thrust
washers and pinion gears.
(c) Install the pinion shaft.
– DIFFERENTIAL ASSEMBLY
2.7 mm (0.106 in.)
