12. Change the Battery Setting (BT) in the Installer
Menu to a number 1 (Extended). Follow the
steps in the menu tree shown in Figure 26.
HYSECURITY
GATE CLOSED
OPEN
CLOSE
STOP
MENU
PREV
NEXT
SELECT
CT 0 (OFF)
CLOSE TIMER
OPEN
CLOSE
STOP
MENU
PREV
NEXT
SELECT
UC 2
USAGE CLASS
OPEN
CLOSE
STOP
MENU
PREV
NEXT
SELECT
BT 1 (EXTENDED)
BATTERY TYPE
OPEN
CLOSE
STOP
MENU
SELECT
PREV
NEXT
Figure 26. Battery Type Selection
51
| www.hysecurity.com
1. Start at a gate
status display.
RESET
2. To access the
User Menu,
press the MENU
button twice.
RESET
3. Access the
Installer Menu, by
simultaneously,
pressing the
OPEN and
RESET
buttons.
RESET
4. Use NEXT to
navigate to the
menu display.
Change the
setting using the
SELECT and
RESET
NEXT buttons.
