Summary of Contents for HySecurity SlideDriver II
- Page 1 SlideDriver ™ SlideDriver II 15 SlideDriver II 40 SlideDriver II 50F SlideDriver II 80V SlideDriver II 200V Slide gate operator EN - User guide...
-
Page 2: Table Of Contents
Maintenance ........15-20 Firmware Updates and Debug Data ..21 Troubleshooting/Alerts/Faults/Errors ... 22-28 Appendix A - French Translations ..29-32 Warranty ............36 Specifications ..........37 SlideDriver II Installer Checklist ... 38-39 Scan the QR code below to go to the warranty registration page. support.hysecurity.com... - Page 3 1. A minimum of three years experience installing similar equipment. Indicates a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS INJURY. 2. Proof of attending a HySecurity Technical Training seminar within the past three years. CAUTION 3. Signifi cant manufacturer endorsements of technical aptitude in gate operator installation and operation.
- Page 4 Class IV: Intended for use in guarded industrial locations or buildings such as an airport security area or other restricted access location, not servicing general Class IV public, in which access is monitored by security personnel or via closed circuitry. support.hysecurity.com...
- Page 5 SAFETY REQUIREMENTS VEHICULAR TRAFFIC ONLY WARNING This automatic gate operator is not designed nor is it intended for pedestrian traffi c. Vehicular gate operators must by their nature be powerful to function reliably. This power can cause injury or death. Accordingly, direct all pedestrian traffi c to a separate walk-through gate.
- Page 6 EXTERNAL ENTRAPMENT PROTECTION an automatic operator is disconnected. SENSORS Most HySecurity gate operators are equipped with a Type A, ● For pedestrian access in the vicinity of an automated Inherent Entrapment Sensor (IES). UL 325 Safety Standard vehicular gate, a separate pedestrian gate shall be provided.
- Page 7 UL 325 requirements in order to be deemed acceptable for use in a gate operator. Study The following sensors have been tested with Nice | HySecurity gate operators by an Important Safety Instructions and consider your specifi c independent laboratory and certified to comply with UL 325 7th Edition.
- Page 8 Installers must assess each specifi c site and *IRB-MON photo eyes are pre-bundled with HySecurity SwingSmart DC, SlideSmart DC and SlideDriver operators. **Sentir Series ASO edge sensors are pre-bundled with HySecurity SlideSmart DC, SlideSmart CNX and SlideDriver operators. install sensors that protect all potential entrapment zones.
- Page 9 OFF before performing ● Never mix battery sizes, types, or brands. Charging circuit maintenance on the gate operator on HySecurity DC operators is designed for AGM-type or making contact with output batteries, not fl ooded lead acid-type batteries. receptacles.
- Page 10 The gate should stop and/or reverse. may cause damage to gate operator and is not covered by the HySecurity Limited Warranty. • With the gate closing, block any photo eyes and/or...
- Page 11 4. Manually push the gate open or close. The external stop button for the SlideDriver II is located on the right side of the chassis. Press the stop button while the gate is opening or closing to stop gate travel and disable the automatic close timer.
-
Page 12: User Interface
Solid Red – Operator is in Menu Mode c. Flashing Green – Operator is in Run Mode d. Flashing Blue – Operator is pairing with a Bluetooth device. e. Alternating Blue and Red/Green – Operator is communicating with a Bluetooth device. support.hysecurity.com... -
Page 13: Entrapment Sensor Wiring
HySecurity provides one edge sensor typically used as PROGRAMMABLE hardwired EDGE OPEN and one photo eye typically used INPUTS as EYE CLOSE with the SlideDriver II 15, 40, 50F, and EMERGENCY INPUT 0 EMERG CLOSE † 1 FIRE DEPT OPEN 80V. -
Page 14: Ies Sensitivity
Note: A second IES trip before Safe Mode is cleared, results in an Entrapment Mode Alert which can be cleared with a Reset on the display, an open input, stop input, or stop button on SlideDriver II cover. support.hysecurity.com... -
Page 15: Maintenance
Motor Brushes (DC Only) Replace Your gate and gate hardware will require more maintenance than your HySecurity operator. A damaged gate or worn hardware may cause slow or erratic operation and will result in excess drive wheel wear. Lubricate gate hardware more frequently and check for smooth operation by opening the toggle clamping mechanism and then pushing the gate manually. - Page 16 Gate Align top of rail Structure with label and notch on the SlideDriver II chassis. CAUTION Rail Height Height from top of drive rail to bottom of gate operator. AD: Advanced Drive Advanced Drive 9¼...
- Page 17 MAINTENANCE Drive Wheel Spring Tension (Adjustment of Manual Release) All SlideDriver II operators come equipped with a toggle handle manual release mechanism to disengage the drive wheels from the drive rail. During shipment, a piece of Styrofoam is placed between the coupling nut and the chassis. If the packaging is still in place, discard it.
- Page 18 Note: Installation instructions are provided with the replacement drive wheels and are accessible online at support. hysecurity.com. A quick look at the drive wheel assembly is shown below. Tighten drive wheel mounting bolts to 18 ft-lb. Figure 7. AdvanceDrive and XtremeDrive Wheels Figure 8.
- Page 19 HySecurity recommends draining the reservoir and replacing the fluid at 24 month intervals. Fluid breakdown caused by heat is the main concern. If the unit is subjected to high use, or you are using the HySecurity biodegradable fluid option (especially in a warm climate), change the fluid more frequently.
- Page 20 For SlideDriver II operators with adjustable brake valves proper adjustment of the brake valves is important for smooth operation of the gate (not all SlideDriver II operators have adjustable brake valves). The position and placement of the limit flags on the drive rail plays an important part on how the brake valves work.
-
Page 21: Firmware Updates And Debug Data
FIRMWARE UPDATES AND DEBUG DATA Download the firmware to a USB flash drive: 1. Go to support.hysecurity.com, click on Software, click SmartCNX Code h6.##, and click h.6.##.cnx to download the .cnx firmware file. 2. Connect a USB flash drive to your computer. -
Page 22: Troubleshooting/Alerts/Faults/Errors
DC power. wiring. 3. Verify Power Type Setting is correct. Firmware is Firmware is currently being loaded. Display being loaded into Wait for firmware to finish LOADING FW will show which specific processor firmware SmartTouch 720/725 loading. is loading. Controller. support.hysecurity.com... - Page 23 No additional automatic function is possible, 21V. but limited push button control is available down to 18V. Critically low 24V supply power. HYSECURITY BAD This message can DC power is below 14V – no control Refer to solutions above. POWER occur only on initial functions will be allowed at all.
- Page 24 5 false. problems or replaced. minutes. * This message will also indicate which detector the alert applies to: Exit Loop (ELD), Inside Obstruction Loop (IOLD), Outside Obstruction Loop (OOLD), or Center Loop (CLD). support.hysecurity.com...
- Page 25 VFD TRIPPED every 15 seconds starts the gate moving, unless the VFD is experiencing a fatal error. If you cannot clear the error alert by pressing the open or close button, contact HySecurity. 1. Check cable Interlock/Sequential connections and Gate communication wiring.
- Page 26 Stop limit flag not LIMIT FAILED Stop limit flag is not detected within 5 clamped, test Open detected after slow seconds of slowdown limit flag. (SlideDriver II 50F (GATE OPENING down limit flag. appears on display). only) Test Close (GATE CLOSING appears on display).
- Page 27 ● The pressure transducer could be bad. ● Loose sensor wires. ● Check that you have the most current sensor; visit support.hysecurity.com and Pressure Transducer Check to see that the ERROR 2 view the technical bulletins. disconnected or not pressure transducer is IES DISCONNECT ●...
- Page 28 Internal firmware/hardware error. Report any ERROR 5 2. Update to latest that SmartTouch instance of this error to HySecurity Technical No display firmware version. 720/725 Controller Support. detects a serious 3. Replace SmartTouch internal error.
-
Page 29: Appendix A - French Translations
APPENDIX A - FRENCH TRANSLATIONS FRENCH TRANSLATIONS The following French translations provided below are found in the Safety Section located at the beginning of the manual. English French INSTRUCTIONS DE SÉCURITÉ IMPORTANTES IMPORTANT SAFETY INSTRUCTIONS AVERTISSEMENT – Pour réduire les risques de WARNING –... - Page 30 Activation être situés dans le champ de visibilité de la of the reset control shall not cause the operator barrière. L’activation des commandes de to start. réenclenchement ne doit pas mettre en marche l’ouvrebarrière. support.hysecurity.com...
- Page 31 APPENDIX A - FRENCH TRANSLATIONS English French 2.9 Au moins deux panneaux de mise en garde 2.9 A minimum of two (2) WARNING SIGNS shall doivent être installés dans la zone de la barrière. be installed, in the area of the gate. Each placard Chaque étiquette doit être visible des personnes is to be visible by persons located on the side of situées de chaque côté...
-
Page 32: Warranty
HySecurity, and the Two Year warranty period in (b), (d), (e), and (f) will not extend force majeure. This warranty does not cover any incidental expenses, including fines beyond four years from the date that the product was shipped from HySecurity. -
Page 33: Specifications
**SlideDriver II SD200 UPS has a 2,000 ft/hr (610 m/hr) expected duty cycle. Actual duty cycle depends on site specifi c conditions and gate confi guration. ***Refer to Installed Options on pricing for all 50Hz voltages, which are special order. -
Page 34: Slidedriver Ii Installer Checklist
SLIDEDRIVER II INSTALLER CHECKLIST This checklist is provided by HySecurity and is to be used after installing a SlideDriver II gate operator. 1. Read, understand, and follow the Safety Requirements section (page 3 - page 11) of this document throughout the commissioning and installation process. - Page 35 SLIDEDRIVER II INSTALLER CHECKLIST 5. Prior to moving the gate, make sure the wheel clamp spring is compressed to 2 in (50 mm). 6. Cycle test the gate by pressing the CLOSE and OPEN buttons. Allow the gate to continue traveling throughout its entire range while you or your assistant checks the following: •...
- Page 36 Nice North America | HySecurity Gate & Barrier Division 6705 S 209th St, Ste 101 hysecurity.com Kent, WA 98032...
