Use the following table as a guide to working with the keypad:
Item
Menu Buttons
4-way directional keypad
Camera
Asterisk / Special Function

4.4 Swipe Down menu

When the DVL is powered on, you can "swipe" your finger from the top of the screen towards the
bottom, to display a Swipe-Down menu (Figure 4-8) with the following items:
Description
The yellow buttons labelled 1 to 8 correspond to menu
choices that appear on the screen.
Controls Up/Down/Left/Right operations in certain menus.
Saves an image of what is displayed on the screen.
Used for adding Flags during data acquisition.
Figure 4-8: Swipe down menu
65
Getting Started
