3.2.3
Attaching Antenna Separation Bars to the SmartCart
The following image displays an assembled SmartCart with separation bars for low frequency
antennas.
Each system has a unique set of separation bars to attach the transducers or low frequency
antennas to the SmartCart and suspend them over the surface.
Before you begin, detach the DVL from the SmartCart and battery as the back half of the cart
may fall to the ground and be damaged.
18
Assembling Full Configurations
