Setting up a CMP survey requires the
(6.2.4) and Step Size
For details of conducting a CMP survey, see
•
WARR – Short for Wide Area Reflection and Refraction. This is very similar to the CMP
survey described above, except that one antenna (Transmitter or Receiver) is fixed and
the other is moved away at set intervals. This can sometimes be easier where space is
a constraint, since only one antenna needs to move, however you need a more uniform
reflector than a CMP.
Setting up a WARR survey requires the
(6.2.4) and Step Size
For details of conducting a WARR survey, see
• Transillumination (ZOP, MOG, VRP)
Transillumination surveys are used to study the properties of a material by placing the
transmitting and receiving antennas at opposite sides of the structure. The GPR signals
travel one-way through the material from the transmitter to the receiver.
Figure 6-13: Common Mid-Point survey
Start Offset
(6.1.3) parameters to be set.
Start Offset
(6.1.3) parameters to be set.
119
(6.2.2), Starting
Section 6.2.1. and Section
(6.2.2), Starting
Section 6.2.1 and Section
System Configuration
Antenna Separation
11.
Antenna Separation
11.
