4. Getting Started

4.1 Powering up the Low Frequency Transmitter and
Receiver
Once all connections are made between the DVL and the antennas/transducers, odometer and
accessories, turn the transmitter and receiver on by pressing the On/Off button on the top of the
units (Figure 4-1).
•
The red Power LED on the top of the unit will flash five times and then stay on to indicate
the unit is ready for operation.
• If the unit doesn't turn on, check that the transmitter and receiver batteries are fully charged
and installed correctly. See
Note: If you are not collecting data for more than 15 minutes, turn the transmitter and
receiver off to increase the life of the batteries.
Figure 4-1: Turning on the Transmitter
Section 2.1.3 for details.
61
