14.2 High Frequency Hardware Specifications

Size (cm)
Size (in)
Weight
Elements
Feed
Cable Interface

14.3 System Specifications

Time Window
Points per Trace
Stacking
Sampling
Data quality assurance
Pulse Repetition Frequency (PRF)
Temporal Sampling Increment (hardware)

14.4 Battery Specifications

Transmitter and Receiver Batteries
(for 12.5, 25, 50, 100, 200 MHz Antennas)
Tow Mode Belt Battery
Grey SmartCart Battery
Battery Charger (for Belt & Grey SmartCart
batteries)
250 MHz
20 x 38 x 38
7.9 x 14.5 x 14.5
3.0 kg (6.6 lbs)
Resistive Dipole
Center Balanced
Metallic cable
500 MHz
16 x 23 x 23
6.5 x 9.1 x 9.1
1.2 kg (2.6 lbs)
Resistive Dipole
Center Balanced
Metallic cable
Up to 192,000 ns
Up to 30,000
2048 (65,536 for Ultra Receiver)
Digital Equivalent Time Sampling (DETS)
Active temperature and voltage compensation
Variable, up to 100 kHz
5 ps
12 Volts, 2.3 AH, 0.8 kg (1.8 lb)
182 x 24 x 62 mm
(7.2 x 0.9 x 2.4 inches)
12 Volts, 9 AH, 2.6 kg (5.7 lb)
160 x 80 x 100 mm
(6.3 x 3.1 x 3.9 inches)
12 Volts, 9 AH, 3.6 kg (7.9 lb)
240 x 190 x 110 mm
(9.4 x 7.5 x 4.3 inches)
AC mains input: 100-240V
Output: 12 Volts @ 3 Amps
212
Technical Specifications
1000 MHz
12 x 15 x 15
4.7 x 5.9 x 5.9
0.6 kg (1.3 lbs)
Resistive Dipole
Center Balanced
Metallic cable
, 1.5A, 50/60Hz
