Assembling Full Configurations
Velcro Straps
Then attach the antennas to the bottom of the separation bars using the metal posts on the
antenna and pins.
Attach the antennas to the SmartCart before attaching the transmitter and receiver (with
batteries inside) to the antennas. To complete all cable connections, see section on
Connecting
Fibre Optic Cables
(3.6.2). Once completed, the assembled SmartCart is shown below with 50
22
