Conquest 100 Main Screen
will also display the number of lines and grids collected in each Project. These will appear under
the Line Scan and Grid Scan buttons respectively.

4.1 Swipe Down menu

When the Display Unit is powered on, you can "swipe" your finger from the top of the screen
towards the bottom, to bring up a drop-down menu with the following items:
Date and Time: The current date and time (12-hour clock) are displayed. The time needs to
be changed for your local time zone.
Battery: The battery icon displays the amount of power remaining in the battery. If the Display
Unit is connected to the battery charger, there will be a flash shown on the battery symbol.
Wi-Fi Network: Indicates if the system is connected to a wireless network and, if so, the name
of the network.
Volume: The Volume + and - buttons are used to increase and decrease the sound.
Brightness: The Brightness + and - buttons are used to increase and decrease the screen
brightness. Increasing the Brightness setting may improve the visibility of the screen in bright
sunlight. Note, however, that increasing the screen brightness also increases power
consumption, reducing battery life.
Figure 4-4: Swipe Down Menu
The version number of the embedded software is displayed in the top left corner.
To close the Swipe Down menu, touch anywhere on the screen below the Swipe Down menu.
