2. tECHnICal SPECIfICatIonS
2.1. Electrical and Mechanical Characteristics
Electrical and Mechanical Characteristics
Power supply
Current consumption in idle state w/o external devices connected
Recommended backup battery voltage, capacity
Recommended backup battery type
Backup battery charge current
Backup battery charge duration
GSM modem frequency
Cable type for GSM/GPRS antenna connection
Number of zones on-board
Nominal zone resistance
Number of PGM outputs on-board
On-board PGM output circuit
Maximum commuting on-board PGM output values (combined)
BeLL: Siren output when activated
BeLL: Maximum siren output current
BeLL: Maximum cable length for siren connection
BeLL: Cable type for siren connection
AUX: Auxiliary equipment power supply voltage
AUX: Maximum accumulative current of auxiliary equipment
AUX: Maximum cable length for auxiliary equipment connection
AUX: Cable type for auxiliary equipment connection
BUZ: Maximum current of mini buzzer
BUZ: Power supply voltage of buzzer
BUZ: Cable type for mini buzzer connection
Supported temperature sensor model
Maximum supported number of temperature sensors
DAtA: Maximum cable length for 1-Wire communication
DAtA: Cable type for 1-Wire communication
Supported iButton key model
Maximum supported number of iButton keys
Maximum supported number of keypads
Y/G: Maximum cable length for RS485 communication
Y/G: Cable type for RS485 communication
MIC: Maximum cable length for microphone connection
MIC: Cable type for microphone connection
Wireless band
Wireless communication range
Maximum supported number of wireless devices
event log size
Maximum supported number of zones
Maximum supported number of PGM outputs
Cable type for zone and PGM output connection
Generated PStN line values
Communications
Supported protocols
Dimensions
Operating temperature range
Humidity
16
16
EN
16-24V 50/60 Hz ~1.5A max / 18-24V
Up to 80mA
12V; 1,3-7Ah
Lead-Acid
Up to 500mA
Up to 30 hours for 7Ah battery
850/900/1800/1900MHz
Shielded
8 (AtZ mode: 16)
5,6kΩ (AtZ Mode: 5,6kΩ and 3,3kΩ)
4
Open collector output.
OUT
1 R
Output is pulled to COM
when turned ON.
4 x 30V; 500mA
Connected to COM
1A
Up to 100m (328.08ft)
Unshielded
13,8V DC
1,1A
Up to 100m (328.08ft)
Unshielded
150mA
12V DC
Unshielded
Maxim®/Dallas® DS18S20, DS18B20
8
Up to 30m (98.43ft)
Unshielded
Maxim®/Dallas® DS1990A
16
4 x eKB2 / eKB3
Up to 100m (328.08ft)
Unshielded
Up to 2m (6.56ft)
Unshielded
ISM868
Up to 3000m (9842.6ft) in open areas
32
1024 events
80
48
Unshielded
Voltage: 48V; current: 25mA; impedance: 270Ω
SMS, Voice calls, GPRS network, CSD, PStN, ethernet via eLAN3-ALARM
Ademco Contact ID, eGR100, Kronos, Cortex SMS, SIA IP
140x100x18mm (5.51x3.94x0.71in)
-20...+55°C (-4... +131°F)
0-90% RH @ 0... +40°C (0-90% RH @ +32... +104°F)
(non-condensing)
ESIM384 Installation and Configuration Manual v1.1
1,5A max
