11. IBUtton KEYS

An iButton key is a unique 64-bit ID code containing chip enclosed in a stainless steel tab usually implemented in a small plastic holder.
eSIM384 system supports up to 16 iButton keys each holding a unique identity code (ID), which is used for system arming and disarming.

11.1. adding and removing iButton Keys

notE: iButton Key 1 can be added without Allow Adding New iButton Keys mode being enabled.
to add an iButton key to the system, do the following:
a) Disarm the system in all partitions (see 12. arMInG anD DISarMInG).
b) enable Allow Adding New iButton Keys mode.
c) touch the key to the iButton key reader when the system is disarmed.
31
d) the successfully added iButton key will be indicated by short beeps emitted by the system's buzzer.
e) Add as many iButton keys as necessary – touch one key after another to the reader – until the number of 16 keys is reached.
Enable allow adding
new iButton Keys
mode
When adding of iButton keys is complete, please disable Allow Adding New iButton Keys mode.
ESIM384 Installation and Configuration Manual v1.1
SMS text message content:
ssss_IBPROG:ON
SMS
Value: ssss – 4-digit SMS password.
Example: 1111_IBPROG:ON
Menu path:
OK → iiii → OK → IBUttON KeYS → OK → NeW IBUttON → OK → eNABLe → OK
EKB2
Value: iiii - 4-digit installer code.
Enter parameter 18 and parameter status value:
EKB3/
18 0 #
EKB3W/
EWKB4
Example: 180#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
41
