Disable EPGM8 mode

18.3. PGM output names

each PGM output has a name that can be customized by the user. typically, the name specifies a device type connected to a determined
PGM output, for Example: Lights. the name can be used instead of PGM output number when controlling the PGM output by SMS text
message. By default, the PGM output names are: C1 – Controll1, C2 – Controll2, C3 – Controll3, C4 – Controll4 etc.
Set PGM output name
View PGM output
names
attEntIon:
Space, colon, semi-colon characters, parameter names and/or values, such as PSW, StAtUS, ON, OFF etc. are NOt allowed in
PGM output names.

18.4. Disabling and Enabling PGM outputs

By default, all PGM outputs are enabled. Once a PGM output is disabled, it can be turned ON or OFF thus the change will not be seen neither
on the eKB2 keypad nor via Cloud platform. to disable/enable a certain PGM output, please refer to the following configuration method.
Disable/enable PGM
outputs

18.5. turning PGM outputs on and off

By default, all PGM outputs are turned OFF. to instantly turn ON/OFF an individual PGM output and set its state to ON/OFF when the system
starts-up, please refer to the following configuration methods.
74 74 EN
Menu path:
OK → iiii → OK → USING ePGM8 → OK → DISABLe → OK
EKB2
Value: iiii – 4-digit installer code.
Enter parameter 33 and parameter status value:
EKB3/
33 0 #
EKB3W/
EWKB4
Example: 330#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_Coo:out-name
SMS
Value: ssss – 4-digit SMS password; oo – PGM output number, range – [1... 80]; out-name –
up to 16 characters PGM output name.
Example: 1111_C2:Lights
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
SMS
ssss_INFO
Value: ssss – 4-digit SMS password.
Example: 1111_STATUS
Menu path:
EKB2 OK → mmmm → OK → PGM OUtPUtS → OK → out-name
Value: mmmm – 4-digit master code; out-name – up to 16 characters PGM output name.
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
softwarel
