Enable parallel data
transmission
Disable parallel data
transmission
30.2.2. Voice Calls and SMS
the system supports up to 3 monitoring station phone numbers for communication with the alarm system by Voice Calls or SMS communi-
cation method using Ademco Contact ID or Cortex SMS data format respectively. tel. Number 1 is mandatory, the other two can be used as
backup phone numbers and are not necessary. the supported phone number formats are the following:
• International (with plus) – the phone numbers must be entered starting with plus and an international country code in the fol-
lowing format: +[international code][area code][local number], example for UK: +44170911XXXX1. this format can be used when
setting up the phone number by ELDES Configuration software.
• International (with 00) – the phone numbers must be entered starting with 00 and an international country code in the following
format: 00[international code][area code][local number], example for UK: 0044170911XXXX1. this format can be used when setting
up the phone number by eKB2/eKB3/eKB3W/eWKB4 keypad.
• local – the phone numbers must be entered starting with an area code in the following format: [area code][local number], example
for UK: 0170911XXXX1. this format can be used when setting up the phone number by eKB2/eKB3/eKB3W/eWKB4 keypad and EL-
DES Configuration software.
to set up the system for data transmission via Voice Calls or SMS, please follow the basic configuration steps:
enable MS Mode parameter (see 30. MonItorInG StatIon).
1.
2. Set 4-digit Main Account number (see 30. MonItorInG StatIon).
3. Set tel. Number 1... 3.
Set monitoring station
phone number
ESIM384 Installation and Configuration Manual v1.1
Menu path:
OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → PARAL.DS.MODe → OK →
EKB2
eNABLe → OK
Value: iiii – 4-digit installer code.
Enter command 96, parameter number and parameter status value:
EKB3/
96 01 1 #
EKB3W/
EWKB4
Example: 96011#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → PARAL.DS.MODe → OK →
EKB2
DISABLe → OK
Value: iiii – 4-digit installer code.
Enter command 96, parameter number and parameter status value:
EKB3/
96 01 0 #
EKB3W/
EWKB4
Example: 96010#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
OK → iiii → OK → MS SettINGS → OK → VOICe CALLS/SMS St → OK → teL. NUMBeR 1... 3 →
EKB2
OK → ttteeellnnuumm → OK
Value: iiii – 4-digit installer code; ttteeellnnuumm – up to 15 digits monitoring station phone
number.
Enter parameter 26, phone number slot and phone number
EKB3/
26 ps ttteeellnnuumm #
EKB3W/
Value: ps – phone number slot, range – [01... 03]; ttteeellnnuumm – up to 15 digits monitor-
EWKB4
ing station phone number.
Example: 26010044170911XXXX1#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
:
