to instantly turn OFF an individual PGM output for a determined time period and automatically turn it ON when the time period expires,
please refer to the following configuration method.
turn off PGM output
for time period
When the PGM output is turned ON or OFF, the system will send a confirmation by SMS text message to the user phone number that the
SMS text message was sent from.
notE:
PGM output can be turned ON for a determined time period only when it is in OFF state
notE: PGM output can be turned OFF for a determined time period only when it is in ON state
notE: Multiple PGM outputs can be turned ON/OFF by a single SMS text message, Example: 1111_C1:ON C2:OFF Pump:ON C4:ON:00.20.25
notE for EWK1/EWK2: Single eWK1/eWK2 keyfob button can be configured to carry out Partition selection and Control output/Output
toggle/Output pulse actions. In such case the PGM output control action will be executed with a 3-second delay once the button is pressed and
in case it is not followed within a 3-second period by a button with arm system or disarm system action assigned.

18.6. PGM output Control by Event and Scheduler

the PGM outputs can automatically operate when a specific event occurs in the system and/or when the scheduled weekday and time
comes.

18.6.1. PGM output actions and System Events

the automatic action of the determined PGM output can be set as follows:
• turn on – Determines whether the PGM output is to be turned ON.
• turn off – Determines whether the PGM output is to be turned OFF.
• Pulse – Determines whether the PGM output is to be turned ON or OFF for a set period of time in seconds based on the PGM output
startup state set up.
the aforementioned PGM output action can be automatically carried out under the following events that have occurred in the system:
• System armed – System is armed in a determined partition ranging from Partition 1 through 4 or any partition.
• System disarmed – System is disarmed in a determined partition ranging from Partition 1 through 4 or any partition.
• alarm begins – Alarm begins in a determined partition ranging from Partition 1 through 4 or any partition.
• alarm stops – Alarm stops in a determined partition ranging from Partition 1 through 4 or any partition.
• temperature falls – temperature falls below the set MIN value of a determined temperature sensor 1-8.
• temperature rises – temperature rises above the set MAX value of a determined temperature sensor 1-8.
• Zone violated – A determined zone ranging from Z1 through Z80 is violated.
• Zone restored – A determined zone ranging from Z1 through Z80 is restored.
• Scheduler starts – Operates based on Start time of a selected scheduler 1-16.
• Scheduler ends – Operates based on end time of a selected scheduler 1-16.
• System fault occurred - A determined system fault is present (for complete list of system faults, please refer to 29. InDICatIon
of SYStEM faUltS).
• System fault restored - A determined system fault is restored (for complete list of system faults, please refer to 29. InDICatIon
of SYStEM faUltS).
the user can also set a custom text, which will be sent by SMS text message to user phone number when the automatic PGM output action
is carried out.
76 76 EN
SMS text message content:
ssss_Coo:OFF:00.00.sc
SMS
Value: ssss – 4-digit SMS password;oo – PGM output number, range – [1... 80]; out-name
– up to 16 characters PGM output name; hr – hours, range – [00... 23]; mn – minutes, range
– [00... 59]; sc – seconds, range – [00... 59].
Example: 1111_Lights:OFF:00.00.23
this operation may be carried out from the wireless keyfob if pre-assigned using the PC run-
EWK1/
EWK2 ning ELDES Configuration software.
or ssss_out-name:OFF:hr.mn.sc
