Set server port
Set DnS1 server IP
address
Set DnS2 server IP
address
ESIM384 Installation and Configuration Manual v1.1
Menu path:
Server 1: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP → OK →
EKB2
SeRVeR IP → OK → add.add. add.add → OK
Server 2: ... → SeRVeR2 IP → OK → SeRVeR IP → OK → add.add. add.add → OK
Server 3: ... → SeRVeR3 IP → OK → SeRVeR IP → OK → add.add. add.add → OK
Value: iiii – 4-digit installer code; add.add.add.add – server IP address.
Enter parameter 40 and server IP address/parameter 96, parameter number and
EKB3/
server IP address:
EKB3W/
Server 1: 40 add add add add #
EWKB4
Server 2: 96 02 add add add add #
Server 3: 96 03 add add add add #
Value: add add add add – server IP address.
Example: 40065082119005#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
Server 1: ssss_SetGPRS:PORt:pprrt
SMS
Value: ssss – 4-digit SMS password; pprrt – server port number, range – [1... 65535].
Example: 1111_SETGPRS:PORT:5521
Menu path:
Server 1: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP → SeRVeR
EKB2
PORt → OK → pprrt → OK
Server 2: ... → SeRVeR2 IP → SeRVeR PORt → OK → pprrt → OK
Server 3: ... → SeRVeR3 IP → SeRVeR PORt → OK → pprrt → OK
Value: iiii – 4-digit installer code; pprrt – server port number, range – [1... 65535].
Enter parameter 44 and server port number/parameter 96, parameter number and
EKB3/
port number:
EKB3W/
Server 1: 44 pprrt #
EWKB4
Server 2: 96 04 pprrt #
Server 3: 96 05 pprrt #
Value: pprrt – server port number, range – [1... 65535].
Example: 443365#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
OK → iiii → OK → GPRS SettINGS → OK → DNS1 → OK → add. add.add. add → OK
EKB2
Value: iiii – 4-digit installer code; add.add.add.add – DNS1 server IP address.
Enter parameter 41 and DnS1 server IP address:
EKB3/
41 add add add add #
EKB3W/
EWKB4
Value: add add add add – DNS1 server IP address.
Example: 41065082119001#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
EKB2
OK → iiii → OK → GPRS SettINGS → OK → DNS2 → OK → add. add.add. add → OK
Value: iiii – 4-digit installer code; add.add.add.add – DNS2 server IP address.
