Eldes ESIM384 Installation Manual page 152

For communication via GPRS network, the GPRS parameters provided by the GSM operator are necessary to be set up. to set those param-
eters, please refer to the following configuration methods.
Set aPn
Set user name
Set password
View IP and GPrS
network settings
152 152 EN
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_SetGPRS:APN:acc-point-name
SMS
Value: ssss – 4-digit SMS password; acc-point-name – up to 31 character APN (Access Point
Name) provided by the GSM operator.
Example: 1111_SETGPRS:APN:internet
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_SetGPRS:USeR:usr-name
SMS
Value: ssss – 4-digit SMS password; usr-name – up to 31 character user name provided by
the GSM operator.
Example: 1111_USER:mobileusr
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_SetGPRS:PSW:password
SMS
Value: ssss – 4-digit SMS password; password – up to 31 character password provided by
the GSM operator.
Example: 1111_SETGPRS:PSW:mobilepsw
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
SMS
ssss_SetGPRS?
Example: 1111_SETGPRS?
Menu path:
Server IP: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP... SeRVeR 2...
EKB2
3 IP → OK → SeRVeR IP
Server port: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP... SeRVeR
2... 3 IP → OK → SeRVeR PORt
DNS1: OK → iiii → OK → GPRS SettNGS → OK → DNS1
DNS2: OK → iiii → OK → GPRS SettNGS → OK → DNS2
Protocol: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP... SeRVeR2...
3 IP → OK → PROtOCOL
APN: OK → iiii → OK → GPRS SettINGS → OK → APN
User name: OK → iiii → OK → GPRS SettINGS → OK → USeRS
Password: OK → iiii → OK → GPRS SettINGS → OK → PASSWORD
Value: iiii – 4-digit installer code.
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
ESIM384 Installation and Configuration Manual v1.1
