Eldes ESIM384 Installation Manual page 140

31 1344 RF jammer detected
32 3344 RF jamming stopped
33 1354 Communication with MS failed
34 3354 Communication with MS
restored
35 1358 GSM connection failed
36 3358 SMS sending limit removed
37 1358 SMS sending limit reached
38 1359 GSM/GPRS antenna fail
39 3359 GSM/GPRS antenna restore
40 1360 IP connection failed
41 1380 CO sensor lifetime exceeded
42 1381 Wireless signal loss
43 3381 Wireless signal restore
44 1401 Disarmed by user
45 3401 Armed by user
46 1403 Disarmed automatically
47 3403 Armed automatically
48 1412 Configuration via remote
connection started
49 1441 Disarmed in Stay mode
50 3441 Armed in Stay mode
51 3456 Armed by user (partial arm)
52 3463 SGS code entered
53 1570 Zone bypassed
54 3570 Bypassed zone activated
55 3602 test event/Kronos ping
56 3626 Date/time not set
57 1900 System started
the following table refers to user IDs included in arm/disarm data messages.
type
User Phone Number 1
User Phone Number 2
User Phone Number 3
User Phone Number 4
User Phone Number 5
User Phone Number 6
User Phone Number 7
User Phone Number 8
User Phone Number 9
User Phone Number 10
iButton 1
iButton 2
iButton 3
iButton 4
iButton 5
iButton 6
140 140 EN
transmitted in case the wireless signal is blocked by jammer.
transmitter in case the wireless signal is restored after jamming.
Transmitted in case t
connections to deliver data message to the monitoring station. this event can be
managed using ELDES Configuration software only.
Transmitted in case t
to the monitoring station within the repeated data delivery cycle initiated after
Delay after last communication attempt time has expired. this event can be man-
aged using ELDES Configuration software only.
transmitted in case the GSM connection is lost.
transmitted in case the SMS text message limit is removed by user or automatically
after the set period of time has come.
transmitted in case the SMS text message limit is reached.
transmitted in case the GSM/GPRS antenna is disconnected/broken
transmitted in case the GSM/GPRS antenna is connected/fixed.
Transmitted in case the GPRS connection or Ethernet connection via ELAN3-
ALARM is lost.
transmitted in case the lifetime of eWF1CO built-in CO sensor is expired.
transmitted in case the connection with any wireless device is lost.
transmitted in case the connection with any wireless device is restored.
transmitted in case the system is disarmed by user/master code, wireless keyfob,
iButton key, SMS text message, free of charge phone call, eLDeS Cloud Services, eL-
DeS Configuration software, eGR100 middle-ware or Arm-Disarm by Zone method.
transmitted in case the system is armed by user/master code, wireless keyfob,
iButton key, SMS text message, free of charge phone call, eLDeS Cloud Services, eL-
DeS Configuration software, eGR100 middle-ware or Arm-Disarm by Zone method.
transmitted in case the system is disarmed automatically according to scheduled
time.
transmitted in case the system is armed automatically according to scheduled time.
transmitted in case the remote connection session is opened.
transmitted in case the system is disarmed in Stay mode.
transmitted in case the system is armed in Stay mode.
transmitted in case the system is armed, while violated zone (-s) with Force attrib-
ute enabled exist.
transmitted in case the SGS code is entered.
transmitted in case a violated zone is bypassed.
transmitted in case a bypassed zone is activated.
transmitted for system online status verification purposes.
transmitted in case system date and time is not set.
transmitted on system startup.
ID type
0 iButton 7
1 iButton 8
2 iButton 9
3 iButton 10
4 iButton 11
5 iButton 12
6 iButton 13
7 iButton 14
8 iButton 15
9 iButton 16
10 Master Code
11 User Code 2
12 User Code 3
13 User Code 4
14 User Code 5
15 User Code 6
he system ends up with all unsuccessful attempts by all
he system has successfully delivered the data message
ID type
16 User Code 7
17 User Code 8
18 User Code 9
19 User Code 10
20 User Code 11
21 User Code 12
22 User Code 13
23 User Code 14
24 User Code15
25 User Code 16
26 User Code 17
27 User Code 18
28 User Code 19
29 User Code 20
30 User Code 21
31 User Code 22
ESIM384 Installation and Configuration Manual v1.1
ID
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
