Enable keypad
partition switch
Disable keypad
partition switch
notE: Keypad partition switch can only be used when the system is partitioned.

23.4. User/Master Code Partition

User/master code partition determines which system partition (-s) can be armed/disarm using a certain user/master code. User/master
code must be assigned to the same partition as the keypad (see 23.3. Keypad Partition and Keypad Partition Switch) in order to arm/
disarm the system by eKB2/eKB3/eKB3W/eWKB4 keypad . For more details on system arming/disarming by the keypad, please refer to
12.3. EKB2 Keypad and User/Master Code, 12.4. EKB3 Keypad and User/Master Code and 12.5. EKB3W/EWKB4 Keypad and
User/Master Code.
Set user/master
code partition
notE for EKB3/EKB3W/EWKB4:
ESIM384 Installation and Configuration Manual v1.1
Menu path:
OK → iiii → OK → PRIMARY SettINGS → OK → KeYPAD PARtItION → OK → PARtItION SWItCH
EKB2
→ OK → eNABLe → OK
Value: iiii – 4-digit installer code.
Enter parameter 77 and parameter status value:
EKB3/
77 1#
EKB3W/
EWKB4
Example: 771#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
OK → iiii → OK → PRIMARY SettINGS → OK → KeYPAD PARtItION → OK → PARtItION SWItCH
EKB2
→ OK → DISABLe → OK
Value: iiii – 4-digit installer code.
Enter parameter 77 and parameter status value:
EKB3/
77 0 #
EKB3W/
EWKB4
Example: 770#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
Master code: OK → mmmm → OK → CODeS → OK → MASteR CODe → OK → PARtItION → OK
EKB2
→ pv → OK
User code 2... 17: ... → CODeS → OK → USeR CODe (2-17) → OK → USeR CODe 2... 17 → OK →
PARtItION → OK → pv → OK
User code 18... 30: ... → CODeS → OK → USeR CODe (18-30) → OK → USeR CODe 18... 30 → OK
→ PARtItION → OK → pv → OK
Value: mmmm – 4-digit master code; pv – partition value, range – [01... 15].
Press , 5, enter 01/user code slot, partition value and master code:
EKB3/
Master code: 5 01 pv mmmm #
EKB3W/
EWKB4
User code: 5 us pv mmmm #
Value: us - user code slot, range - [02... 30]; pv – partition value, range – [01... 15]; mmmm -
4-digit master code.
Example: 504081111#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
the Configuration mode must be deactivated, while managing user and master code partition.
