Eldes ESIM384 Installation Manual page 62

Disable Chime
attribute
Enable Chime attribute
By default, Cross-Zone/Intelli-Zone is not set. to associate two zones and/or set the Alarm Confirmation timeout, please refer to the fol-
lowing configuration method.
associate a zone for
Cross-Zone/Intelli-Zone
attribute
Set alarm
Confirmation timeout
Set alarm Count to
Bypass attribute for
individual zone
attEntIon: Cross-Zone/Intelli-Zone feature is NOt recommended in case it is necessary to bypass the associated zone, otherwise the zone
that requires alarm confirmation will never cause an alarm when violated.
62 62 EN
Menu path:
OK →iiii → OK → ZONeS → OK → CHIMe → OK → DISABLe → OK
EKB2
Value: iiii – 4-digit installer code.
Enter parameter 32 and parameter status value:
EKB3/
32 0 #
EKB3W/
EWKB4
Example: 320#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
OK →iiii → OK → ZONeS → OK → CHIMe → OK → eNABLe → OK
EKB2
Value: iiii – 4-digit installer code.
Enter parameter 32 and parameter status value:
EKB3/
32 1 #
EKB3W/
EWKB4
Example: 321#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
ElDES
Config-
uration this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
ElDES
Config-
uration
this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
ElDES
Config-
uration this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
ESIM384 Installation and Configuration Manual v1.1
