d) Run ELDES Configuration software.
e) Select the newly replaced temperature sensor ID from the drop-down list of the temperature sensor slot that was previously associated
with a faulty temperature sensor.
remove/replace
individual
temperature sensor

24.2. Primary and Secondary temperature Sensors

Any out of 8 available temperature sensors can be set as primary or secondary. the real-time temperature values of the primary and sec-
ondary temperature sensors are included in the Info SMS text message (see 26. SYStEM InforMatIon. Info SMS) as well as the tem-
perature measured by the primary temperature sensor is indicated in the home screen view of eKB2 keypad.
to set temperature sensors as primary or secondary, please refer to the following configuration methods.
Set primary
temperature sensor
Set secondary
temperature sensor
to view the slot number of primary and secondary temperature sensors, please refer to the following configuration methods.
116 116 EN
ElDES
Config-
uration this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
SMS text message content:
ssss_teMPI:PRIM:ts
SMS
Value: ssss – 4-digit SMS password; ts – temperature sensor slot, range - [1... 8].
Example: 1111_TEMPI:PRIM:4
Menu path:
OK → iiii → OK → PRIMARY SettINGS → OK → teMP SeNSORS → OK → PRIMARY teMP SeNS
EKB2
→ OK → 1... 8 CONNeCteD → OK
Value: iiii – 4-digit installer code.
Enter parameter 89 and temperature sensor slot:
EKB3/
89 ts #
EKB3W/
Value: ts – temperature sensor slot, range - [01... 08].
EWKB4
Example: 8903#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_teMPI:SeC:ts
SMS
Value: ssss – 4-digit SMS password; ts – temperature sensor slot, range - [1... 8].
Example: 1111_TEMPI:SEC:3
Menu path:
OK → iiii → OK → PRIMARY SettINGS → OK → teMP SeNSORS → OK → SeCOND. teMP SeNS
EKB2
→ OK → 1... 8 CONNeCteD → OK
Value: iiii – 4-digit installer code.
Enter parameter 90 and temperature sensor slot:
EKB3/
90 ts #
EKB3W/
Value: ts – temperature sensor slot, range - [01... 08].
EWKB4
Example: 9005#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
