duration, please refer to the following configuration methods.
Set mains power loss
delay
Set mains power
restore delay
For more details on how Send SMS text message to all users simultaneously and SMS Cascade parameters affect the SMS text message
transmission, please refer to 27. SYStEM notIfICatIonS.
21.3. Memory
the configuration settings and event log records are stored in a built-in memory, therefore even if the system is fully shut down, the config-
uration and event log remain. For more details regarding the event log, please refer to 28. EVEnt anD alarM loG.
108 108 EN
Menu path:
OK → iii → OK → PRIMARY Sett INGS → OK → MAIN POWeR StAtUS → OK → LOSS DeLAY →
EKB2
OK → lllll → OK
Value: iiii – 4-digit installer code; lllll – mains power loss delay duration, range - [0... 65535]
seconds.
Enter parameter 70 and loss delay duration:
EKB3/
70 lllll #
EKB3W/
Value: lllll – mains power loss delay duration, range - [0... 65535] seconds.
EWKB4
Example: 7043#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
OK → iiii → OK → PRIMARY Sett INGS → OK → MAIN POWeR StAtUS → OK → ReStORe DeLAY
EKB2
→ OK → rrrrr → OK
Value: iiii – 4-digit installer code; rrrrr – mains power restore delay duration, range - [0...
65535] seconds.
Enter parameter 71 and restore delay duration:
EKB3/
71 rrrrr #
EKB3W/
Value: rrrrr – mains power restore delay duration, range - [0... 65535] seconds.
EWKB4
Example: 71150#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
