20.5. Indication by EWS3 - Wireless Indoor Siren Indicators

When enabled, the built-in LeD indicators of eWS3 wireless indoor siren will flash during the alarm. In the event of burglary, 24-hour or
tamper alarm, eWS3 will flash the blue LeD indicators, while in case of a fire alarm, the device can flash the red LeD indicator. to enable/
disable these features, please refer to the following configuration methods.
Enable EWS3 lED
indication
Disable EWS3 lED
indication
104 104 EN
Menu path:
EKB2
Burglary/24-hour/tamper alarm LeD:
SettINGS → OK → eWS3 ALARM LeD → OK → eNABLe → OK
Fire alarm LeD: ... → SIReN SettINGS → OK → eWS3 FIRe LeD → OK → eNABLe → OK
Value: iiii – 4-digit installer code.
Enter parameter 94/93 and parameter status value:
EKB3/
Burglary/24-hour/tamper alarm LeD:
EKB3W/
Fire alarm LeD: 93 1 #
EWKB4
Example: 931#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
Burglary/24-hour/tamper alarm LeD:
EKB2
SettINGS → OK → eWS3 ALARM LeD → OK → DISABLe → OK
Fire alarm LeD: ... → SIReN SettINGS → OK → eWS3 FIRe LeD → OK → DISABLe → OK
Value: iiii – 4-digit installer code.
Enter parameter 94/93 and parameter status value:
EKB3/
Burglary/24-hour/tamper alarm LeD:
EKB3W/
Fire alarm LeD: 93 0 #
EWKB4
Example: 940#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
OK → iiii → OK → PRIMARY Sett INGS → OK → SIReN
94 1 #
OK → iiii → OK → PRIMARY Sett INGS → OK → SIReN
94 0 #
