arm the system
• Partitioned system – arming a single partition – to arm a different partition than the keypad is assigned to, use keypad partition
switch feature (by default – disabled; see 23.3. Keypad Partition and Keypad Partition Switch) before the arming process.
Switch keypad par-
tition
Once the partition is switched and a valid user/master code is entered, the system will initiate exit delay, the keypad's buzzer will emit short
beeps and the indicator along with the number [1]... [4] key, indicating the partition that is to be armed, will light ON. When the system is
successfully armed, the keypad's buzzer will silent down.
arm the system
• Partitioned system - arming all 4 partitions simultaneously – If a user/master code assigned to all 4 partitions exists, user can
arm all partitions simultaneously. When this feature is used, the system will proceed as follows:
• if all partitions are disarmed-ready (no violated zone/tamper), the system will initiate exit delay. During the exit delay, the keypad's
buzzer will emit short beeps and indicator
armed, the keypad's buzzer will silent down.
• if one or more partitions are disarmed unready (keypad number [1]... [4] key flashing, indicating the partition that contains violated
zone/tamper), the system will initiate exit delay. During the exit delay, the keypad's buzzer will emit short beeps and keypad indicator
(if the keypad is switched to a non-violated partition) along with the number [1]... [4] key, indicating the partition that is to be
armed, will light ON. the ready partition (-s) will be armed and the unready one (-s) will be skipped.
• if a combination of armed and disarmed ready partitions is present, the system will initiate exit delay. During the exit delay, the
keypad's buzzer will emit short beeps and keypad indicator
number [1]... [4] key, indicating the partition that is to be armed, will light ON. the disarmed-ready partitions will be armed and the
pre-armed ones will be skipped.
arm all 4 partitions
simultaneously
Alternatively, the user can arm multiple partitions one by one (see Partitioned system - arming a single partition above).
notE: If the user fails to enter a correct user/master code 10 times in a row, the system will block the keypad for 2 minutes. While the
keypad is blocked, the system prevents from entering any user/master code. the keypad will automatically unblock once the 2-minute
time has expired/
notE: Before arming all 4 partitions simultaneously, the user/master code must be assigned to all 4 partitions and the keypad parti-
tion switch feature enabled (see 23.3. Keypad Partition and Keypad Partition Switch).
12.4.2. Cancelling System arming
to cancel the arming process, enter the user/master code again during exit delay countdown.
12.4.3. Disarming the System and turning off the alarm
to disarm and turn OFF the alarm, enter any out of 29 available 4-digit user codes or master code using the number keys on the keypad. By
default, the system disarming process is as follows:
• non-partitioned system – When a valid user/ master code is entered, indicator
Disarm the system and
turn off the alarm
• Partitioned system – disarming a single partition – to disarm a different partition than the keypad is assigned to, use keypad partition
switch feature (by default – disabled; see 23.3. Keypad Partition and Keypad Partition Switch) before the disarming process.
48 48 EN
Enter user/master code:
uumm
Value: uumm – 4-digit user/master code.
Example: 2222
Hold the [1]... [4] key and release it after 3 short beeps:
Value: [1]... [4] key – partition number 1... 4 respectively.
Enter user/master code:
uumm
Value: uumm – 4-digit user/master code.
Example: 2222
along with number [1], [2], [3] and [4] keys will light ON. When the system is successfully
Hold the [0] key, release it after 3 short beeps and enter user/ master code:
0 uumm
Value: uumm – 4-digit user/master code.
Example: 0 2222
Enter user/master code:
uumm
Value: uumm – 4-digit user/master code.
Example: 2222
(if the keypad is switched to a disarmed partition) along with the
and the number [1] key will light OFF.
