  • Page 1 ESIM364 GSM ALARM AND MANAGEMENT SYSTEM INSTALLATION MANUAL...
  • Page 2 Please read and follow these safety guidelines in order to maintain safety of operators and people around: • GSM alarm & management system ESIM364 (also referenced as alarm system, system or device) has radio transceiver operating in GSM 850/900/1800/1900 bands.

  • Page 3: Table Of Contents

    18.6. Wireless PGM Output Type Definitions ............................... 67 19. WIRELESS DEVICES ................................68 19.1. Binding, Removing and Replacing Wireless Devicess ..........................68 19.2. Wireless Device Information and Signal Status Monitoring ........................70 19.3. Disabling and Enabling Siren if Wireless Signal is Lost ..........................71 MANUAL ELDES ESIM364 V1.5...
  • Page 4 31. DUAL SIM MANAGEMENT ..............................117 31.1. Disabled Mode........................................117 31.2. Automatic Mode ......................................117 31.3. Manual Mode ......................................... 119 32. ELDES WIRED DEVICES ................................121 32.1. RS485 Interface ......................................121 32.2. 1-Wire Interface ......................................134 32.3. Modules Interface ......................................135 33. ELDES WIRELESS DEVICES..............................139 33.1.
  • Page 5 “ELDES UAB” will not take any responsibility regarding personal or property or revenue loss while using the system. “ELDES UAB” liability according to local laws does not exceed value of the purchased system. “ELDES UAB” is not affiliated with any of the cellular providers therefore is not responsible for the quality of cellular service.

  • Page 6: General Information

    * - A mixed combination of EKB2 and EKB3 keypads is supported. The combination can consist of up to 4 keypads in total. ** - Only 1 of these modules can be connected at a time if the module slots are implemented in ESIM364 unit.
  • Page 7 EKB3/ Configuration SMS EKB2 EKB3W Tool Alarm Duration 1 minute     EWS2 LED Disabled   Bell Squawk Disabled    Activate Siren if Wireless Device is Lost Disabled    MANUAL ELDES ESIM364 V1.5...
  • Page 8 Tamper Alarm Disabled    Keypad Failed Enabled    Temperature Info Enabled     System Started Enabled    Periodical Info Enabled    Wireless Signal Loss Enabled   MANUAL ELDES ESIM364 V1.5...
  • Page 9   Unit ID (GPRS) 0000    Test Period (GPRS) 180 seconds    Communication - Primary    Communication - Backup 1... 5    Protocol over GPRS EGR100  MANUAL ELDES ESIM364 V1.5...
  • Page 10 Try to Find Operator for a Maximum of 3 times  Smart Security Configurable by: Parameter Default Value EKB3/ Configuration SMS EKB2 EKB3W Tool Smart Security Disabled  Server Address ss.eldes.lt  Port 8082  180 seconds Ping Period  Time Zone  MANUAL ELDES ESIM364 V1.5...
  • Page 11 MANUAL ELDES ESIM364 V1.5...

  • Page 12: Technical Specifications

    Cable type for zone and pgm output connection Unshielded Communications SMS, Voice calls, GPRS network, RS485, CSD, PSTN Supported protocols Ademco Contact ID, EGR100, Kronos, Cortex SMS Dimensions 140x100x18mm Operating temperature range -20...+55 °C Humidity 0-90% RH @ 0... +40 °C (non-condensing) MANUAL ELDES ESIM364 V1.5...

  • Page 13: Main Unit, Led & Connector Functionality

    Negative power supply terminal for auxiliary equipment AUX+ Positive power supply terminal for auxiliary equipment AC/DC Main power supply terminals AKU- Backup battery negative terminal AKU+ Backup battery positive terminal * - Optional, implementable on request in advance MANUAL ELDES ESIM364 V1.5...

  • Page 14: Wiring Diagrams

    Based on the example given, in the event of an alarm, the smoke detector could be reset by turining OFF and ON the PGM output C1. For more details, please refer to 18.4. Turning PGM Outputs ON and OFF. NOTE: The system does NOT support 2-wire smoke detectors. MANUAL ELDES ESIM364 V1.5...
  • Page 15 5,6 k 3,3 k 5,6KΩ end-of-line resistor, 5,6KΩ end-of-line resistor with normally closed Magnet contact and 3,3KΩ end-of-line resistor with normally closed contact. +Vin TAMP See also 14.3. 6-Zone Mode and 14.4. ATZ (Advanced Technology Zone) Mode. MANUAL ELDES ESIM364 V1.5...
  • Page 16 BELL- is the commuted terminal intended for siren control. NOTE: Siren status monitoring feature supervises the resistance across BELL+ and BELL- terminals. The resistance must be ranging from 1kΩ through 3,3kΩ, otherwise the system will indicate system fault. MANUAL ELDES ESIM364 V1.5...
  • Page 17 2.3.6. Relay Finder 40.61.9.12 with Terminal Socket 95.85.3 to PGM Output 1 Wire up relay A1 terminal to PGM output Cx and A2 terminal to AUX+. 2 In addition, connect LED indicator‘s anode ter- minal to relay A2 terminal and cathode to A1 terminal. COIL RELAY MANUAL ELDES ESIM364 V1.5...
  • Page 18 You may connect only 1 EKB2/EKB3 keypad or a mixed combination of EKB2 and EKB3 keypads. The combination can consist of up to 4 keypads in total. For more details on RS485 device installation, please refer to 32.1. RS485 Interface MANUAL ELDES ESIM364 V1.5...
  • Page 19 If necessary, the RS485 devices can be powered from an external 12-14V DC power supply instead of AUX+ and AUX- terminals ATTENTION: The cable between ESIM364 and each RS485 device must be of the same length and can NOT exceed 100 meters. ATTENTION: When wiring more than 1 keypad and/or EPGM1 module, please ensure that the set address of each keypad and/or EPGM1 module is different.

  • Page 20: Installation

    Secondary voltage: 17V 2,35A) Tamper switch to AC/DC terminals of ESIM364 system 2. Insert the plastic standoffs into the appropriate mounting points and fix the board of ESIM364 on the holders as indicated below. mounting points MANUAL ELDES ESIM364 V1.5...
  • Page 21 3. If EPGM1 module is to be installed, please install it in the first place and ESIM364 alarm system afterwards. EPGM1 must be mounted on the shorter plastic standoffs, while ESIM364 – on the longer ones. The mounting points of EPGM1 module are indicated below.
  • Page 22 SIM card into the SIM CARD2 slot. For more details, please refer to 31. DUAL-SIM MANAGEMENT. Inserting a SIM card into SIM CARD1 slot is mandatory as it is the main SIM card slot, while using a SIM card in SIM CARD2 slot is optional. MANUAL ELDES ESIM364 V1.5...
  • Page 23 For more details on how to install the wireless devices, please refer to 33. ELDES WIRELESS DEVICES and RADIO SYSTEM IN- STALLATION AND SIGNAL PENETRATION manual located at www.eldes.lt/download 9. Power up the system and wait until indicator STAT lights up.

  • Page 24: General Operational Description

    NOTE: Even though alarm system ESIM364 installation process is not too complicated, we still recommend to perform it by a person with basic knowledge in electrical engineering and electronics to avoid any system damage. 4. GENERAL OPERATIONAL DESCRIPTION When the system is being armed, it will initiate the exit delay countdown intended for the user to leave the secured area. During the count- down period the buzzer will emit short beeps.

  • Page 25: Configuration Methods

    35. EN 50131-1 GRADE 3. In order to configure and control the system by SMS text message, send the text command to the ESIM364 system phone number from one of the preset user phone numbers. The structure of SMS text message consists of 4-digit SMS password (the default SMS password is 0000 –...
  • Page 26 Before configuring ESIM364 remotely via GPRS connection, make sure that: • SIM card is inserted into SIM CARD1 slot of ESIM364 device (see 2.2. Main Unit, LED & Connector Functionality). • Mobile internet service (GPRS) is enabled on the SIM card.
  • Page 27 In case it is necessary to establish a connection between ESIM364 system and a third-party Initiate the configuration server, send the following SMS text message. connection to third-party server SMS text message content: ssss_STCONFIG:add.add.add.add:Port ssss_STCONFIG:host-name:pprrt Value: ssss – 4-digit SMS password; add.add.add.add – public IP address of third-par- ty configuration server;...

  • Page 28: Passwords

    0000, which MUST be changed! • Administrator password – 4-digit password used for Configuration mode activation by keypad and logging in to ELDES Configuration Tool software. By default, Administrator password is 1470, which is highly recommended to change.

  • Page 29: System Language

    The system comes equipped with a single language for communication with the user by SMS text messages and EKB2 keypad menu display. The system language depends on ESIM364 firmware, which is based on the user’s location. List of currently available system languages (firmwares): •...

  • Page 30: User Phone Numbers

    International (with 00) – The phone numbers must be entered starting with 00 and an international country code in the following format: 00[international code][area code][local number], example for UK: 004417091111111. This format can be used when set- ting up the phone number by SMS text message, EKB2/EKB3/EKB3W keypad and ELDES Configuration Tool software. •...

  • Page 31: User Phone Number Names

    SETTINGS → OK → USERS → OK → USER 2... 10 → OK → PHONE NUMBER → OK → OK Value: aaaa – 4-digit administrator password. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool ATTENTION: NEVER add a phone number of the device’s SIM card as a user phone number!
  • Page 32 Value: aaaa – 4-digit administrator password. Enter parameter 12 & parameter status value: EKB3/ 12 0 # EKB3W Example: 120# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool MANUAL ELDES ESIM364 V1.5...

  • Page 33: Date And Time

    – [00... 23]; mn – minutes, range – [00... 59]. Example: 66201305291235# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: When the system is connected to the monitoring station via GPRS network connection (see 30. MONITORING STATION) and/or when Smart Security feature is in use (see 35.

  • Page 34: User Passwords

    [0000... 9999]. Example: 15021111# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: OK → CONFIGURATION → OK → aaaa → OK → PRIMARY SETTINGS → OK → PASSWORDS →...

  • Page 35: User Password Names

    Example: 7403# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool The Duress password is used when system disarming is demanded by force. When used, the system will disarm as well as it will silently transmit an alert to the monitoring station.

  • Page 36: Ibutton Keys

    An iButton key is a unique 64-bit ID code containing chip enclosed in a stainless steel tab usually implemented in a small plastic holder. ESIM364 system supports up to 16 iButton keys each holding a unique identity code (ID), which is used for system arming and disarming.

  • Page 37: Ibutton Key Names

    18 1 # EKB3W Example: 181# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool To view the ID of the added iButton keys, please refer to the following configuration methods. Menu path: OK →...

  • Page 38: Arming And Disarming

    (-s). The system will then send an SMS text message, containing a list of violated zones/tampers, to user phone number that the system arming was initiated from. • If a combination of armed and disarmed ready partitions is present, the system will arm the disarmed ready partitions and skip the armed ones. MANUAL ELDES ESIM364 V1.5...

  • Page 39: Sms Text Message

    To disarm the system by SMS text message, send the following text to the system‘s phone number from any of 10 available user phone numbers: SMS text message content: ssss_DISARMp ssss_DISARMp,p,p,p Disarm the system Value: ssss – 4-digit SMS password; p – partition number, range – [1... 4]. Example: 1111_DISARM1,2,4 User ESIM364 MANUAL ELDES ESIM364 V1.5...

  • Page 40: Ekb2 Keypad And User Password

    → OK → [p] part-name → OK Value: uuuu – 4-digit user password; p – partition number, range – [1... 4], part-name – up to 15 characters partition name. Example: 1111 → OK → [3] GARAGE → OK MANUAL ELDES ESIM364 V1.5...

  • Page 41: Ekb3 Keypad And User Password

    For more details on keypad partition switch and how to enable it, please refer to 23.3. Keypad Partition and Keypad Partition Switch. Hold the [1]... [4] key and release it after 3 short beeps: Use keypad partition Value: [1]... [4] key – parition number 1... 4. switch MANUAL ELDES ESIM364 V1.5...

  • Page 42: Ekb3W Keypad And User Password

    To disarm the system by EKB3W keypad, enter any out of 30 available 4-digit user passwords using the number keys on the keypad. By default, when a valid user password is entered, EKB3W keypad indicator ARMED will light OFF. Enter user password: uuuu Disarm the system Value: uuuu – 4-digit user password. Example: 1111 MANUAL ELDES ESIM364 V1.5...

  • Page 43: Ibutton Key

    For example, if iButton 5 is assigned to Partition 1 and 4, the user will be able to arm/ disarm Partition 1 and 4 by touching iButton 5 to the reader. For more details on how to set iButton key partition, please refer to 23.5. iButton Key Partition. MANUAL ELDES ESIM364 V1.5...

  • Page 44: Ewk1/Ewk2 Wireless Keyfob

    Partition 3. To arm a different partition than the EWK1/EWK2 wireless keyfob is assigned to, bind another EWK1/EWK2 keyfob to the system and assign it to a different partition. For more details on how to manage EWK1/EWK2 keyfob buttons, please refer to ELDES Configuration Tool software‘s HELP section.

  • Page 45: Disabling And Enabling Arm/Disarm Notifications

    EKB3W Example: 3400# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool 12.9. Disabling and Enabling Arm/Disarm Notifications By default, when the system is successfully armed or disarmed, it replies with confirmation by SMS text message to: •...
  • Page 46 Enter parameter 22 & parameter status value: EKB3/ 22 1 # EKB3W Example: 221# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Disable arm/disarm Menu path: EKB2 notification for all OK → CONFIGURATION → OK → aaaa → OK → PRIMARY SETTINGS → OK → CALL/SMS preset user phone SETTINGS →...

  • Page 47: Exit And Entry Delay

    Example: 7203259# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: Alternatively, you can set exit delay value to 0 in order to arm the system without exit delay by any available method.
  • Page 48 Example: 5403259# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: Due to battery power saving reasons, EKB3W keypad buzzer will not sound during exit and entry delay if the violated Delay type zone is not of the associated EKB3W keypad.

  • Page 49: Zones

    14.3. 6-Zone Mode By default, ESIM364 alarm system runs in the 6-Zone mode under zone connection Type 1 allowing to connect up to 6 detection devices of NO (normally-open) type to the on-board zone terminals as indicated in the wiring diagram of Type 1. Once a different zone connection type is set, the detection device wiring must be done according to the wiring diagram of the associated type.

  • Page 50: Atz (Advanced Technology Zone) Mode

    – Type 3 Example: 392# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool 14.4. ATZ (Advanced Technology Zone) Mode The ATZ mode is a software-based feature that doubles the number of on-board zones and enables two detection devices to be installed per 1 zone terminal.

  • Page 51: Zone Type Definitions

    38 2 # – Type 5 Example: 381# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: The ATZ mode applies to on-board zones only when enabled. 14.5. Zone Type Definitions •...

  • Page 52: Zone Attributes

    Enter parameter 56, zone number & parameter status value: EKB3/ 56 nn 1 # EKB3W Value: nn – zone number, range – [01... 76]. Example: 56041# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool MANUAL ELDES ESIM364 V1.5...
  • Page 53 EKB3W Value: nn – zone number, range – [01... 76]. Example: 56190# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: On-board zone: OK → CONFIGURATION → OK → aaaa → OK → ZONES → OK → ONBOARD...

  • Page 54: Bypassing And Activating Zones

    Enable/disable Config Shared attribute for This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool individual zone Config Set Delay, ms atrribute This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 55: Zone Names

    Value: ssss – 4-digit SMS password; nn – zone number, range – [1... 76]; zone-name – up to 24 characters zone name. Example: 1111_Z3:Door sensor triggered Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_STATUS View zone names Value: ssss –...

  • Page 56: Disabling And Enabling Zones

    52 nn 0 # EKB3W Value: nn – zone number, range – [01... 76]. Example: 52360# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_Znn:ON Enable zone Value: ssss –...

  • Page 57: Stay Mode

    The system can be armed in Stay mode, only if there is at least one zone with Stay attribute enabled. NOTE: Stay mode is not supported by virtual zones. For more details on how to enable Stay attribute for zone, please refer to 14.6. Zone Attributes. MANUAL ELDES ESIM364 V1.5...

  • Page 58: Tampers

    25 18 0 # - Wireless signal loss Example: 25180# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: Tamper alarm: OK → CONFIGURATION → OK → aaaa → OK → SMS MESSAGES 2 → OK →...

  • Page 59: Alarm Indications And Notifications

    To silent the siren/bell as well as to cease system phone calls and SMS text message sending to the user phone numbers, please disarm the system (see 12. ARMING AND DISARMING). SMS text message content: ssss_INFO View violated zones Value: ssss – 4-digit SMS password. Example: 1111_INFO Menu path: EKB2 OK → VIOLATED ZONES → OK → ZONE 1... 76 MANUAL ELDES ESIM364 V1.5...

  • Page 60: Enabling And Disabling Alarm Notifications

    29. INDICATION OF SYS- TEM FAULTS. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool The systemwill automatically send an SMS text message, containing a violated tamper name, View violated tampers to user phone number.
  • Page 61 Example: 301# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool By, default the system will send SMS text message to preset user phone numbers in case of alarm. To disable/enable this feature, please refer to the following configuration methods.

  • Page 62: Audio Files

    Example: 210# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool By default, tamper alarm notification by SMS text message is enabled. For more details on how to disable/enable tamper alarm notification, please refer to 16.

  • Page 63: Programmable (Pgm) Outputs

    When a PGM output turns ON, the system triggers any device or relay connected to it. ESIM364 comes equipped with four open-collector PGM outputs allowing to connect up to four devices or relays. For more details on PGM output expanding, please refer to 18.2. PGM Output Expansion.

  • Page 64: Pgm Output Names

    Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: EKB2 OK → CONFIGURATION → OK → aaaa → OK → PGM OUTPUTS → OK → USING EPGM8 → OK Disable EPGM8 mode →...
  • Page 65 61 oo 1 # EKB3W Value: oo – PGM output number, range – [01... 76]. Example: 61031# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: Turn OFF PGM output/ ssss_Coo:OFF...

  • Page 66: Pgm Output Control By Event And Scheduler

    The PGM output will not operate until the chain of system events meets the set values: • System armed – System is armed in a determined partition ranging from 1 to 4 or any partition. MANUAL ELDES ESIM364 V1.5...

  • Page 67: Wireless Pgm Output Type Definitions

    Partition 2 is disarmed. Manage PGM output Config control by event & This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool scheduler NOTE: When both - a system event is determined and a scheduler is selected, the PGM output will operate only if the determined event has occurred in the system during the scheduled time period.

  • Page 68: Wireless Devices

    The rest of attempts - every 2 minutes. Once the wireless device is bound, it will attempt to exchange data with ESIM364 system. Due to battery saving reasons, all ELDES wireless devices operate in sleep mode. The data exchange will occur instantly if the wireless device is triggered (zone alarm or tamper alarm) or pe- riodically when the wireless device wakes up to transmit the supervision signal, identified as Test Time, to the system as well as to accept the queued up command (if any) from the system.
  • Page 69 If you are unable to bind a wireless device, please restore the wireless device’s parameters to default and try again. For more details on how to restore the default parameters, please refer to the user manual provided along with the wireless device or visit www.eldes.lt/en/...

  • Page 70: Wireless Device Information And Signal Status Monitoring

    – 8-digit wireless device ID code. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool The system supports up to 32 wireless devices. To view the number of unoccupied wireless device slots in the system, please refer to the...

  • Page 71: Disabling And Enabling Siren If Wireless Signal Is Lost

    EKB3/ 76 1 # EKB3W Example: 761# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: Disable Siren if EKB2 OK → CONFIGURATION → OK → aaaa → OK → PRIMARY SETTINGS → OK → SIREN SETTINGS Wireless Signal is Lost →OK →...

  • Page 72: Siren/Bell

    10 tt # EKB3W Value: tt – alarm duration, range – [00... 10] minutes. Example: 1007# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_SIREN View alarm duration Value: ssss –...

  • Page 73: Bell Output Status Monitoring

    EKB3/ 25 08 1 # EKB3W Example: 25081# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: Disable Siren Fail/ EKB2 OK → CONFIGURATION → OK → aaaa → OK → SMS MESSAGES 1 → OK → SIREN FAIL/REST Restore notification EV →...

  • Page 74: Indication By Ews2 Indicators

    EKB3W Example: 290# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool 20.3. Indication by EWS2 Indicators When enabled, the built-in LED indicators of EWS2 wireless outdoor siren will flash during the alarm. To enable/disable this feature, please refer to the following configuration methods.

  • Page 75: Ewf1 Interconnection

    Value: aaaa – 4-digit administrator password. Enter parameter 29 & parameter status value: EKB3/ 50 0 # EKB3W Example: 500# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool MANUAL ELDES ESIM364 V1.5...

  • Page 76: Backup Battery, Mains Power Supply Status Monitoring And Memory

    EKB3/ 50 1 # EKB3W Example: 501# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Config Set EWF1 siren alarm Tool This operation may be carried out from the PC using the ELDES Configuration Tool software.
  • Page 77 EKB3W Example: 25060# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool OK → CONFIGURATION → OK → aaaa → OK → SMS MESSAGES 1 → OK → BATTERY DEAD/ Enable Battery Dead EKB2 MISS →...
  • Page 78 EKB3/ 25 04 0 # EKB3W Example: 25040# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: Enable mains power EKB2 OK → CONFIGURATION → OK → aaaa → OK → SMS MESSAGES 1 → OK → MAIN POWER L/R supply loss/restore EV →...
  • Page 79 Example: 71150# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool The configuration settings and event log records are stored in a built-in EEPROM memory, therefore even if the system is fully shut down, the configuration and event log remain.

  • Page 80: Gsm Connection And Antenna Status Monitoring

    EKB3/ 25 11 1 # EKB3W Example: 25111# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: Disable GSM EKB2 OK → CONFIGURATION → OK → aaaa → OK → SMS MESSAGES 2 → OK → GSM CONNECT Connection Failed FAILED →...
  • Page 81 EKB3/ 25 12 1 # EKB3W Example: 25121# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Menu path: Disable GSM/GPRS EKB2 OK → CONFIGURATION → OK → aaaa → OK → SMS MESSAGES 2 → OK → GSM ANT FAIL/REST Antenna Fail/Restore →...

  • Page 82: Partitions

    23. PARTITIONS ESIM364 system comes equipped with a partitioning feature that can divide the alarm system into four independently controlled areas identified as Partition 1 through 4, which are all supervised by one alarm system unit. Partitioning can be used in installations where shared alarm system is more practical, such as a house and a garage or within a single multi-storey building.

  • Page 83: Keypad Partition And Keypad Partition Switch

    08]; p – EKB2/EKB3 partition number, range – [1... 4]; r – EKB3W partition number, range – [1... 2]. Example: 51062# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: The keypad can only be assigned to one partition.

  • Page 84: User Password Partition

    77 0 # EKB3W Example: 770# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: Keypad partition switch can only be used when the system is partitioned. 23.4. User Password Partition User password partition determines which system partition (-s) can be armed/disarm using a certain user password.

  • Page 85: Ibutton Key Partition

    Value: ii – iButton key slot, range – [01... 16]; pv – partition value (see 23. PARTITIONS). Example: 600511# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool 23.6. EWK1/EWK2 Wireless Keyfob Partition EWK1/EWK2 wireless keyfob partition determines which system partition can be armed/disarmed using a certain EWK1/EWK2 wireless keyfob.

  • Page 86: Temperature Sensors

    OK → TEMP SENSORS INFO → OK → 1. tm.p C (PRIM) | (SEC)... 8. tm.p C EKB2 Value: tm.p – real-time temperature value. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: View real-time...

  • Page 87: Primary And Secondary Temperature Sensors

    89 ts # EKB3W Value: ts – temperature sensor slot, range - [01... 08]. Example: 8903# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_TEMPI:SEC:ts Set secondary temperature sensor Value: ssss –...

  • Page 88: Setting Up Min And Max Temperature Boundaries. Temperature Info Sms

    OK → TEMP SENSORS INFO → OK → 1... 8 tm.p C (SEC) Value: tm.p – real-time temperature value. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: Primary and secondary temperature sensors can be set by a single SMS text message, Example: 1111_TEMPI:PRIM:4,SEC:3 24.3.

  • Page 89: Temperature Sensor Names

    Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: MIN and MAX boundaries can also be set separately by multiple SMS text messages, Example: 1111_TEMP1:MIN:6 and 1111_ TEMP1:MAX:40 24.4. Temperature Sensor Names The temperature sensor name is included in the Temperature Info SMS when delivered to the User 1 phone number.

  • Page 90: Remote Listening And 2-Way Voice Communication

    25. REMOTE LISTENING AND 2-WAY VOICE COMMUNICATION ESIM364 comes equipped with a microphone that allows the user to listen on his mobile phone to what is happening in the secured area. By installing one of the audio modules EA1 or EA2, the user will be able to have a 2-way voice communication (see 32.3.2. EA1 – Audio Output Module and 32.3.3.

  • Page 91: System Information. Info Sms

    Value: ssss – 4-digit SMS password. Example: 1111_INFO Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool 26.1. Periodic Info SMS By default, the system sends Info SMS to User 1 phone number periodically once a day at 11:00 (frequency – 1 day; time – 11). The mini- mum period is every 1 hour (frequency –...
