12.8. arm-Disarm by Zone

the Arm-Disarm by Zone feature allows to use a zone for arming and disarming the alarm system. the process is performed by
arM/
applying a low-level pulse for more than 3 seconds to the specified zone. It means that violating and restoring the zone leads to
DISarM
system arming and by repeating this action the system becomes disarmed. the system will arm/disarm the partition (-s) that
ZonE
the zone is assigned to. Up to 4 on-board zones can be set to arm/disarm up to 4 system partitions by this method.
Set zone for arm-
Disarm by Zone
method
Disable arm-Disarm by
Zone method

12.9. automatic arm/Disarm by Scheduler

the system comes equipped with an automatic arm/disarm feature that operates according to the specified weekday and time. this fea-
ture requires to set up the Start time value of a certain scheduler and assign it to either Arm System or Disarm System action, which is
associated with a certain partition (all partitions).
Manage automatic
arm/disarm method
For more details on the scheduler management, please refer to 18.6.2. Schedulers.

12.10. Disabling and Enabling arm/Disarm notifications

By default, when the system is successfully armed or disarmed, it replies with confirmation by SMS text message to:
• user phone number, sharing the same partition as eKB2/eKB3/eKB3W/eWKB4 keypad and user/master code, iButton key, eWK1/
eWK2 wireless keyfob or zone, set up for Arm/Disarm by Zone method.
• user phone number that the system arming/disarming by free of charge phone call was initiated from.
• user phone number that the system arming/disarming by SMS text message was initiated from.
the confirmation SMS text message is sent to the user phone number regarding each partition separately and contains system status and
partition name as well as it may contain a user name assigned to user phone number, user/master code or iButton key. For more details on
names, please refer to 8.1. User Phone number names, 10.1. User/Master Code names and 11.2. iButton Key names.
to disable/enable this notification for individual user phone number, please refer to the following configuration methods.
Disable arm/disarm
notification
ESIM384 Installation and Configuration Manual v1.1
Menu path:
OK → iiii → OK → ZONeS → OK → ARM/DISARM BY ZONe → OK → ZONe 1... 4 → OK → nn
EKB2
Value: iiii – 4-digit installer code; nn – on-board zone number, range – [01... 16].
Enter parameter 34, on-board zone slot and zone number:
EKB3/
34 z nn #
EKB3W/
Value: z – on-board zone slot for Arm-Disarm by Zone method; range - [1... 4]; nn – on-board
EWKB4
zone number, range – [01... 16].
Example: 34023#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
EKB2
OK → iiii → OK → ZONeS → OK → ARM/DISARM BY ZONe → OK → ZONe 1... 4 → OK → 0
Value: iiii – 4-digit installer code.
Enter parameter 34, on-board zone slot and parameter status value:
EKB3/
34 z 00 #
EKB3W/
Value: z – on-board zone slot for Arm-Disarm by Zone method; range - [1... 4].
EWKB4
Example: 34200#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
System armed:
EKB2
User phone number:
GSM USeR 1... 10 → OK → DISABLe → OK
SMS text message to all users simultaneously:
→ OK → DISABLe → OK
SMS delivery report:
OK → iiii → OK → SMS MeSSAGeS 1 → OK → SYS ARMeD eVeNt → OK →
... → SYS ARMeD eVeNt → OK → SMS tO ALL
... → SYS ARMeD eVeNt → OK → SMS RePORt → OK → DISABLe → OK
