12.6. iButton Key

to arm or disarm the system and turn OFF the alarm, touch the iButton key reader by any of 16 available iButton keys (see 11.
iBUtton KEYS for iBut ton key management). When the iButton is touched to the iButton key reader for arming, the system
will proceed as follows:
non-partitioned system:
• If ready (no violated zone/tamper), the system will initiate exit delay and arm.
• If unready, the system will not arm and provide a list of violated zones/tampers by SMS text message to user phone num-
ber. In such case the user must restore all violated zones and tampers before arming the system. Alternatively, the violated
zones can be bypassed (see 14.7. Bypassing and activating Zones), disabled (see 14.9. Disabling and Enabling
Zones) or a Force attribute enabled (resulting in partial arm; see 14.6. Zone attributes), while the tampers can be dis-
abled (see 16. taMPErS).
Partitioned system:
• If all partitions are disarmed ready (no violated zone/tamper), the system will initiate exit delay and arm them.
• If one or more partitions are disarmed unready (violated zone/tamper is present), the system will arm the ready par tition
(-s) and skip the unready one (-s).
• If a combination of armed and disarmed ready partitions is present, the system will initiate exit delay, arm the disarmed
ready partitions and skip the armed ones.
When an iButton key is assigned to multiple partitions, the user will be able to arm/disarm the corresponding system partitions
by touching the iButton key to the reader. For example, if iButton 5 is assigned to Partition 1 and 4, the user will be able to arm/
disarm Partition 1 and 4 by touching iButton 5 to the reader. For more details on how to set iButton key partition, please refer
to 23.5. iButton Key Partition.
