attEntIon: the system will NOt send any data to the monitoring station while remote connection, remote firmware update or remote
listening/2-way voice communication is in progress. However, during the remote connection session or remote listening/2-way voice com-
munication process, the data messages will be queued up and transmitted to the monitoring station after the remote connection session or
remote listening/2-way voice communication process is over, while during the remote firmware update process NO data will be queued up
and all data messages will be lost.
attEntIon: Phone calls via GSM network to the listed user phone number in case of alarm are disabled by force when MS mode is enabled.
notE: Additional charges may apply for voice calls/data traffic based on your cell phone service plan when using the MS mode.
30.1. Data Messages – Events
the configuration of data messages is based on Ademco Contact ID protocol. the data messages can either be transmitted to the monitor-
ing station alone or with duplication by SMS text message to listed user phone number. For more details on system notifications by SMS text
message, please refer to 27. SYStEM notIfICatIonS.
Seq. no. Event Event
Code
1 1110 Fire alarm
2 3110 Fire restore
3 1120 Silent/Panic zone alarm
4 3120 Silent/Panic zone restore
5 1121 Disarmed by user (Duress
code)
6 3121 Armed by user (Duress code)
7 1130 Burglary alarm
8 3130 Burglary restore
9 1133 24-Hour zone alarm
10 3133 24-Hour zone restore
11 1144 tamper alarm
12 3144 tamper restore
13 1146 Instant Silent zone alarm
14 3146 Instant Silent zone restore
15 1150 Report/Control zone trigger
16 3150 Report/Control zone restore
17 1158 temperature risen
18 1159 temperature fallen
19 1162 CO level critical
20 1301 Mains power loss
21 3301 Mains power restore
22 1302 Low battery
23 1308 System shutdown
24 1309 Battery failed
25 1311 Battery dead or missing
26 3311 Battery connection restore
27 1321 Siren fail
28 3321 Siren restore
29 1330 Communication bus fail
30 3330 Communication bus restore
ESIM384 Installation and Configuration Manual v1.1
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Description
transmitted in case a zone of Fire type is violated.
transmitted in case a zone of Fire type is restored.
transmitted in case a zone of Silent/Panic type is violated.
transmitted in case a zone of Silent/Panic type is restored.
transmitted in case the system is disarmed by Duress code.
transmitted in case the system is armed by Duress code.
transmitted in case a zone of Delay (if not disarmed before entry delay countdown
is completed), Interior Follower or Instant type is violated.
transmitted in case a zone of Delay (if not disarmed before entry delay countdown
is completed), Interior Follower or Instant type is restored.
transmitted in case of zone of 24-Hour type is violated.
transmitted in case of zone of 24-Hour type is restored.
transmitted in case the tamper is violated.
transmitted in case the tamper is restored.
transmitted in case of zone of Instant Silent type is violated.
transmitted in case of zone of Instant Silent type is restored.
transmitted in case of zone of Report/Control type is triggered.
transmitted in case of zone of Report/Control type is restored.
transmitted in case of the temperature has increased above the MAX set value.
transmitted in case of temperature has decreased below the MIN set value.
transmitted in case the critical level 4 of carbon monoxide (CO) concentration de-
tected by eWF1CO is reached.
transmitted in case the mains power is lost.
transmitted in case the mains power is restored.
transmitted in case the backup battery voltage is 10.5V or lower / the wireless de-
vice battery level runs below 5%.
When the system is running on backup battery power, it transmits the data mes-
sage before the backup battery power is fully depleted.
transmitted in case the backup battery resistance is 2Ω or higher.
transmitted in case the backup battery is not present or the battery voltage runs
below 5V.
transmitted in case the backup battery connection is fixed.
transmitted in case the siren is disconnected/broken.
transmitted in case the siren is connected/fixed.
transmitted in case the RS485 device, such as keypad, eLAN3-ALARM or ePGM1 is
disconnected/broken.
transmitted in case the RS485 device, such as keypad, eLAN3-ALARM or ePGM1
is connected/fixed
