5. ConfIGUratIon MEtHoDS

!!! In this installation manual the underscore character "_" represents one space character. every underscore character must
be replaced by a single space character. there must be no spaces or other unnecessary characters at the beginning and at
the end of the SMS text message.

5.1. SMS text Messages

In order to configure and control the system by SMS text message, send the text command to the eSIM384 system phone
number from one of the listed user phone numbers. the structure of SMS text message consists of 4-digit SMS password
SMS
(the default SMS password is 0000 – four zeros), the parameter and value. For some parameters the value does not apply e. g.
StAtUS. the variables are indicated in lower-case letters, while a valid parameter value range is indicated in brackets.
notE:
By default the SMS password is 0000, which is necessary to change.

5.2. EKB2 lCD Keypad

the system configuration and control by eKB2 keypad is carried out by navigating throughout the menu section list displayed
on LCD screen. to navigate in the menu path, touch ↓, ↑ keys to select the desired menu section and touch OK key to open the
EKB2
selected section. to enter a required value, use 0... 9 keys and touch OK key for confirmation or cancel/go one menu section
back by touching ← key. the value can be typed in directly by touching 0... 9 keys while highlighting the desired menu section.
eKB2 menu type is "circle", therefore when the last section in the menu list is selected, you will be brought back to the begin-
ning of the list after touching the ↓ key. In this installation manual, the menu path is based on the eKB2 menu tree by starting
at home screen view (see 32.1.1.2. Master and User Menu tree and 32.1.1.3. Installer Menu tree). the variables are
provided in lower-case letters, while a valid parameter value range is provided in brackets.
activate
Configuration mode
Deactivate
Configuration mode
notE:
By default, menu section CONFIGURAtION is secured with installer code. the default installer code is 1470, while the default master
code is 1111.
notE: the system can be configured using only one keypad at a time. Other connected keypads will be inactive while the menu section
CONFIGURAtION is opened. the inactive eKB2 keypads will display
notE: the keypad will automatically exit the menu section CONFIGURAtION and return to home screen view if 1 minute after the last
key-touch expires.
ESIM384 Installation and Configuration Manual v1.1
Menu path:
OK → iiii → OK
EKB2
Value: iiii - 4-digit installer code.
EKB2 Return to home screen view
icon.
