Set user code
Delete user code
notE: the system does not allow to set a duplicate code.
the user codes ranging from User code 2 through 10 can be set as SGS (Security Guard Service) code, which is used as a checkpoint by a
security service guard upon his/her visit in the secured location. When used, a data message, containing a certain event code, will be deliv-
ered to the monitoring station. However, NO system arming or disarming will be carried out after entering the SGS code.
Set SGS code
the Duress code is used when system arming or disarming is demanded by force. When used, the system will arm/disarm as well as it will
silently transmit an alert to the monitoring station. Only one of the user codes ranging from User code 2 through 10 can be set as Duress code.
Set Duress code
ESIM384 Installation and Configuration Manual v1.1
Menu path:
User code 2... 16: OK → mmmm → OK → CODeS → OK → USeR CODe (2-16) → OK → USeR CODe
EKB2
2... 16 → OK → CODe → OK → uuuu → OK
User code 17... 30:
CODe 17... 30 → OK → CODe → OK → uuuu → OK
Value: mmmm – 4-digit master code; uuuu – 4-digit user code, range – [0000... 9999].
Press , 0, enter master code, user code slot and user code:
EKB3/
0 mmmm us uuuuu #
EKB3W/
Value: mmmm - 4-digit master code; us - user code slot, range - [02... 30]; uuuu - 4-digit user
EWKB4
code, range - [0000... 9999].
Example: 01111092556#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
EKB2
OK → mmmm → OK → CODeS → OK → ReMOVe CODe → OK → uuuu → OK
Value: mmmm – 4-digit master code; uuuu – 4-digit user code.
Press , 0, enter master code and user code slot:
EKB3/
0 mmmm us #
EKB3W/
Value: mmmm - 4-digit master code; us - user code slot, range - [02... 30].
EWKB4
Example: 0111109#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
EKB2
OK → mmmm → OK → CODeS → OK → SGS CODe → OK → N/A | USeR CODe 2... 10 → OK
Value: mmmm – 4-digit master code; N/A – SGS code not in use.
Press , 4, enter user code slot and enter master code:
EKB3/
4 us mmmm #
EKB3W/
EWKB4
Value: us - user code slot, range - [02... 10]; mmmm - 4-digit master code.
Example: 4041111#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
EKB2
OK → mmmm → OK → CODeS → OK → DUReSS CODe → OK → N/A | USeR CODe 2... 10 → OK
Value: mmmm – 4-digit master code; N/A – Duress code not in use.
Press , 3, enter user code slot and master code:
EKB3/
3 us mmmm #
EKB3W/
Value: us - user code slot, range - [02... 10]; mmmm - 4-digit master code.
EWKB4
Example:
3081111#
OK → mmmm → OK → CODeS → OK → USeR CODe (17-30) → OK → USeR
