14.7. Bypassing and activating Zones

notE for EKB3/EKB3W/EWKB4:
passed zone.
Zone bypassing allows the user to deactivate a violated zone and arm the system without restoring the zone. If a bypassed zone is violated
or restored during exit/entry delay, or when then system is armed, it will be ignored. When a zone is bypassed, eKB3/eKB3W/eWKB4 key-
pad indicator will light ON and eKB2 keypad will display
Bypass individual
violated zone
Bypass all violated
zones
the zone will remain bypassed until the system is disarmed. Once the system is disarmed, the corresponding zone state will be indicated
on the keypads (see 32.1.1. EKB2 – lCD Keypad, 32.1.2. EKB3 – lED Keypad and 19.5. EKB3W/EWKB4 – Wireless lED Keypad )
and Info SMS text message (see 26. SYStEM InforMatIon. Info SMS). Alternatively, the user can activate the bypassed zone by the
following configuration methods.
activate bypassed
zone
notE: Zones can only be bypassed and activated when the system is not armed.

14.8. Zone names

each zone has a name that can be customized by the user. typically, the name specifies a device type connected to a determined zone
terminal, for Example: Kitchen doors opened. the zone names are used in SMS text messages that are sent to the user during alarm, the
By default, the zone names are: Z1 – Zone1, Z2 – Zone2, Z3 – Zone3, Z4 – Zone4 etc.
Set zone name
ESIM384 Installation and Configuration Manual v1.1
the Configuration mode must remain deactivated before bypassing a violated zone or activating a by-
icon in the home screen view.
Menu path:
OK → uumm → OK → BYPASS → OK → BYPASS LISt 1... 9 → OK → Z1-zone-name... Z80-zone-
EKB2
name → OK → BYPASS → OK
Value: uumm – 4-digit user/master code; zone-name – up to 24 characters zone name.
Press the key, enter zone number and user/master code:
EKB3/
nn uumm #
EKB3W/
Value: nn – zone number, range – [01... 80]; uumm – 4-digit user/master code.
EWKB4
Example: 091111#
Menu path:
OK → uumm → OK →BYPASS → OK → BYP VIOLAteD ZONeS → OK
EKB2
Value: uumm – 4-digit user/master code.
Menu path:
EKB2
OK → uumm → OK → BYPASS → OK → BYPASS LISt 1... 9 → OK → Z1-zone-name... Z80-zone-
name → OK → UNBYPASS → OK
Value: uumm – 4-digit user/master code; zone-name – up to 24 characters zone name.
Press the key, enter zone number and user/master code:
EKB3/
nn uumm #
EKB3W/
EWKB4
Value: nn – zone number, range – [01... 80]; uumm – 4-digit user/master code.
Example: 251111#
SMS text message content:
ssss_Znn:zone-name
SMS
Value: ssss – 4-digit SMS password; nn – zone number, range – [1... 80]; zone-name – up to
24 characters zone name.
Example: 1111_Z3:Door sensor triggered
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
