Eldes ESIM4 User Manual

Battery powered gsm auto dialler/mini alarm system
Hide thumbs Also See for ESIM4:
Table of Contents

Advertisement

Quick Links

Download this manual
ESIM4
ESIM4 Q
Battery Powered GSM Auto Dialler/
Mini Alarm System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESIM4 and is the answer not in the manual?

Questions and answers

Related Manuals for Eldes ESIM4

Summary of Contents for Eldes ESIM4

  • Page 1 ESIM4 ESIM4 Q Battery Powered GSM Auto Dialler/ Mini Alarm System...

  • Page 2: User Manual

    • DO NOT attempt to repair the system yourself – any repairs must be carried out by fully qualified personnel only. ESIM4 is a device that must be installed in limited access areas. Any system repairs must be done only by qualified, safety aware personnel.

  • Page 3: Table Of Contents

    3. INSTALLATION ...................................9 4. GENERAL OPERATIONAL DESCRIPTION..........................10 5. CONFIGURATION METHODS ..............................10 5.1. SMS Text Messages ......................................10 5.2. ELDES Configuration Tool ....................................10 5.3. QR Codes ...........................................11 6. SMS PASSWORD ..................................11 7. USER PHONE NUMBERS ................................12 8. DATE AND TIME..................................13 8.1.

  • Page 4: V Lithium Aa Batteries

    The buyer agrees that the system will reduce the risk of fire, theft, burglary or other danger but that it does not guarantee against the oc- currence of such events. “ELDES UAB” will not take any responsibility for the loss of personal effects, property or revenue whilst using the system.
  • Page 5 Hereby, “ELDES UAB” declares that the battery pow- ered GSM auto dialler/mini alarm system ESIM4 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The declaration of conformity may be consulted at www.eldes.lt.

  • Page 6: General Information

    1. GENERAL INFORMATION ESIM4 is a micro-controller based device used to inform users about the alarm in automatic or security systems, supply power to an auxiliary device and control one electrical appliance or measure temperature. The device can also be used as a mini-alarm system.

  • Page 7: Main Unit And Led And Connector Functionality

    NOTE: We recommend using Camelion P7 lithium 1.5V AA type and Energizer Ultimate lithium 1.5V AA type batteries or other ‘‘ELDES UAB’’ recommended batteries. 2.2. Main Unit and LED and Connector Functionality Main Unit Functionality GSM MODEM GSM network 900/1800 MHz modem...

  • Page 8: Wiring Diagrams

    COM Z2 Z1 ESIM4 ESIM4 COM Z2 Z1 COM Z2 Z1 5,6K iButton BUZZER key reader 5,6K iButton BUZZER key reader Magnet Magnet Example of input wiring in ATZ mode iButton key reader and buzzer wiring Magnet Magnet ESIM4 Manual v1.5...

  • Page 9: Installation

    Wire up the system in accordance with the wiring diagrams (see 2.3 Wiring Diagrams for more details). 2. If necessary to run the wires, drill out a hole of 13mm (0.51in) diameter in the ESIM4 enclosure and insert the plastic gland supplied in ESIM4 package.

  • Page 10: General Operational Description

    For more details on how to encrypt an SMS text message in a QR code, please refer to 5.3. QR Codes and ELDES Configuration Tool software’s HELP section.

  • Page 11: Qr Codes

    5.3. QR Codes For user convenience, ELDES Configuration Tool software comes equipped with QR code generator allowing to arrange a single or multiple text commands in a single SMS text message and encrypt it in a QR code. Once the QR code is generated, the user using his mobile phone’s built-in camera can take a picture of the code right from his monitor’s screen, then decrypt it to the SMS text message using his mobile...

  • Page 12: User Phone Numbers

    Value: ssss – 4-digit SMS password; up – user phone number slot, range – [1... 10]; ttteeelln- nuumm – up to 15 digits user phone number. Example: 1111_NR1:+44170911XXXX1 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Config View user phone This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 13: Date And Time

    – [01... 31]; hr – hours, range – [00... 23]; mn – minutes, range – [00... 59]. Example: 1111_CLK:2013.03.16_14:33 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content:...

  • Page 14: Sleep And Wake-Up Modes

    Value: ssss – 4-digit SMS password; se – seconds, range – [0... 65535]. user Example: 1111_MONT:25 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Config View Wake-Up mode This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 15: Wake-Up Scheduler

    Value: ssss – 4-digit SMS password; c – scheduler number, range – [1... 5]; hr – hours, range – [00... 23]; mn – minutes, range – [00... 59]. Example: 1111_ERT4:15:02_19:00 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_ERTc:OFF Disable scheduler Value: ssss –...

  • Page 16: Inputs

    Z1 and input Z2 Value: ssss – 4digit SMS password. Example: 1111_ATZ:1;1; Config Config Tool This operation may be carried out from the PC using the ELDES Configuration Tool Tool software. SMS SMS text message content: Disable ATZ mode for ssss_ATZ:0;0...

  • Page 17: Digital Mode

    Value: ssss – 4-digit SMS password; vthr – threshold, range - [0... 3000] mV Example: 1111_Z1VLEV:2350 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: Set input as NC...

  • Page 18: Analog Mode

    4) When the current drops below the threshold, it will result in input state change to restore followed by notifying the user by SMS text message and/or phone call. Config Set period This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: Set threshold for...

  • Page 19: Input Z2

    Disable AUX output Value: ssss – 4-digit SMS password. Example: 1111_AUX:OFF Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Config View real-time AUX This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 20: Digital Mode

    Config View input mode This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool parameters 10.2.1. Digital Mode When Digital mode is set, the system follows this pattern: Monitors input voltage ranging from 0 mV through 3000 mV every 1 second.

  • Page 21: Temperature Sensor Mode

    Value: ssss – 4-digit SMS password; temp-per – temperature update period, range – [3... 71000000] minutes. Example: 1111_PTEMP:45 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Adding, Removing and Replacing Temperature Sensors To add a temperature sensor to the system, proceed as follows: Shut down the system.
  • Page 22 - [-55... 125] C; temp-name – up to 8 characters temperature sensor name. Example: 1111_TEMP3:-14:32:House Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool View MIN and Config MAX temperature This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 23: Ibutton Key Mode

    An iButton key is a unique 64-bit ID code containing chip enclosed in a stainless steel tab usually implemented in a small plastic holder. ESIM4 system supports up to 8 iButton keys each holding a unique identity code (ID), which is used for system arming and disarming (see 15.

  • Page 24: Alarm/Restore Notifications

    Value: ssss – 4-digit SMS password; i – input number, range – [1... 4]. Example: 1111_SAZ1:OFF Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_SAZi:ON Enable input alarm notification Value: ssss –...
  • Page 25 Value: ssss – 4-digit SMS password; i – input number, range – [1... 4] Example: 1111_SRZ2:OFF Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_SRZi:ON Enable input restore notification Value: ssss –...

  • Page 26: Alarm Delay

    Value: ssss – 4-digit SMS password; i – input number, range – [1... 4]. Example: 1111_CAZ2:ON Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_CAZi:OFF...

  • Page 27: Shock Sensor

    11. SHOCK SENSOR ESIM4 has a built-in shock sensor that detects the surface vibrations of the location where the device is installed. This feature allows to receive the alarm/restore notifications by SMS text message to the listed user phone number in accordance with the number of set up shakes in a certain time period (by default –...

  • Page 28: Alarm/Restore Notification Scheduler

    Value: ssss – 4-digit SMS password; hr – hours, range – [00... 23]; mn – minutes, range – [00... 59]. Example: 1111_TIME:08:00_19:15 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_ETIME:OFF Disable scheduler Value: ssss –...

  • Page 29: Output

    Rename output Value: ssss – 4-digit SMS password; out-name – up to 23 characters output name Example: 1111_TC1:Lamp Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_STATUS View output name Value: ssss –...
  • Page 30 Example: 1111_C1:OFF Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool To instantly turn ON the output for a determined time period and automatically turn it OFF when the time period expires, please refer to the following configuration methods.
  • Page 31 Value: ssss – 4-digit SMS password. Example: 1111_STATUS Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool NOTE: The output can be turned ON for a determined time period only when it is in OFF state...

  • Page 32: Battery Level Monitoring

    Value: ssss – 4-digit SMS password; lev – low battery level, range – [1... 100] %. low battery level Example: 1111_LOWB:3 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_TLOWB:lowb-text...

  • Page 33: Arming And Disarming

    15. ARMING AND DISARMING ESIM4 comes equipped with mini-alarm system features allowing arming and disarming. Before using this feature, the iButton Key mode must be selected for Input Z2 and iButton key (-s) must be added to the system. For more details on iButton key management, please refer to 10.2.3.

  • Page 34: System Information. Status Sms

    Example: 1111_STATUS Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool By default, the aforementioned items, except System name, are excluded from the Status SMS. To include them, please refer to the following configuration method.

  • Page 35: System Notifications

    15. ARMING AND DISARMING Disarmed SMS text message sent to the user in case the system is disarmed. For more details on how to manage this notification, please refer to 15. ARMING AND DISARMING ESIM4 Manual v1.5...
  • Page 36 Value: ssss – 4-digit SMS password; start-text – up to 23 characters System Started notifi- and set the text cation text. Example: 1111_SSMS:ESIM4 started Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_SSMS:OFF Disable System Started notification Value: ssss –...

  • Page 37: Event Memory

    - [1... 1000] minutes. and period Example: 1111_LOG:8-15 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool SMS text message content: ssss_LOG:OFF Disable event memory Value: ssss – 4-digit SMS password.

  • Page 38: Remote Listening

    19. REMOTE LISTENING ESIM4 may be equipped with a microphone that allows the user to listen on his mobile phone to what is happening in the area surrounding the microphone. Remote listening feature can operate under the following conditions: The system makes a phone call to a listed user phone number in case of input alarm/restore and the user answers the call (see also •...

  • Page 39: Technical Support

    If your problem could not be fixed by the self-guide above, please contact your local distributor. More up to date information about your device and other products can be found at the manufacturer’s website www.eldes.lt 20.2. Restoring Default Parameters 1.

  • Page 40: Related Products

    21. RELATED PRODUCTS Adhesive flat GSM antenna DS18S20 - temperature sensor Microphone Magnet mount straight GSM antenna DS1990A-F5 - iButton key ED1T - plastic enclosure with iButton key reader and temperature sensor ESIM4 Manual v1.5...
  • Page 41 ESIM4 Manual v1.5...
  • Page 42 ESIM4 Manual v1.5...
  • Page 44 Made in the European Union www.eldes.lt...
