Setting Up Min And Max Temperature Thresholds. Temperature Info Sms - Eldes ESIM384 Installation Manual

View primary and
secondary temperature
sensor slot number
View primary and
secondary temperature
sensor real-time
temperature values
notE: Primary and secondary temperature sensors can be set by a single SMS text message, Example: 1111_TEMPI:PRIM:4,SEC:3

24.3. Setting Up MIn and MaX temperature thresholds. temperature Info SMS

the system supports an SMS text message identified as the temperature Info SMS, which is automatically delivered to the listed user
phone number if the specified minimum (MIN) or maximum (MAX) temperature threshold of any temperature sensor is exceeded by at
least 1°C. In case of temperature threshold's is exceeded, an event data message will be sent to the monitoring station
to set the MIN and MAX temperature thresholds for a certain temperature sensor, please refer to the configuration methods.
Set MIn and MaX
temperature
boundaries
View MIn and
MaX temperature
boundaries
ESIM384 Installation and Configuration Manual v1.1
SMS text message content:
ssss_teMPI:?
SMS
Value: ssss – 4-digit SMS password.
Example: 1111_TEMPI:?
Menu path:
Primary: OK → uumm → OK → teMP SeNSORS INFO → OK → 1... 8 tm.p C (PRIM)
EKB2
Secondary: ... → teMP SeNSORS INFO → OK → 1... 8 tm.p C (SeC)
Value: uumm - 4-digit user/master code; tm.p – real-time temperature value.
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
SMS
ssss_INFO
Value: ssss – 4-digit SMS password.
Example: 1111_INFO
Menu path:
Primary: OK → uumm → OK → teMP SeNSORS INFO → OK → 1... 8 tm.p C (PRIM)
EKB2
Secondary: ... → teMP SeNSORS INFO → OK → 1... 8 tm.p C (SeC)
Value: uumm - 4-digit user/master code; tm.p – real-time temperature value.
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_teMPts:MIN:mnn,MAX:mxx
SMS
Value: ssss – 4-digit SMS password; ts - temperature sensor slot, range – [1... 8]; mnn – MIN
boundary, range – [-55... 125] C; mxx - MAX boundary, range – [-55... 125] °C.
Example: 1111_TEMP2:MIN:-5,MAX:28
Menu path:
MIN: OK → iiii → OK → PRIMARY SettINGS → OK → teMP SeNSORS → OK → teMPeRAtURe
EKB2
SeNS 1... 8 → OK → teMP. MIN → OK → mnn → OK
MAX: ... → teMPeRAtURe SeNS 1... 8 → OK → teMP. MAX → OK → mxx → OK
Value: iiii – 4-digit installer code; mnn – MIN boundary, range – [-55... 125] °C; mxx - MAX
boundary, range – [-55... 125] °C.
Keys P1 or P2 are used to enter minus character, e.g. -20.
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
ssss_teMPts
SMS
Value: ssss – 4-digit SMS password; ts - temperature sensor slot, range – [1... 8].
Example: 1111_TEMP4
117
EN 117
