Set attempts
to report the online status, the system periodically transmits (by default – every 180 seconds) test event data message (ping) to the mon-
itoring station via GPRS network or ethernet.
Set test period
notE: 0 value disables test period. However, disabling the test period is HIGHLY UNReCOMMeNDeD.
Unit ID is a 4-digit number (By default – 0000) required to identify the alarm system unit by eGR100 middle-ware. It is ReCOMMeNDeD to
change the default Unit ID before using eGR100.
Set unit ID
ESIM384 Installation and Configuration Manual v1.1
Menu path:
Server 1: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP → OK → IP
EKB2
AtteMPtS → OK → att → OK
Server 2: ... → SeRVeR2 IP → OK → IP AtteMPtS → OK → att → OK
Server 3: ... → SeRVeR3 IP → OK → IP AtteMPtS → OK → att → OK
Value: iiii – 4-digit installer code; att – number of attempts, range – [1... 255].
Enter parameter 68 and number of attempts/parameter 96, parameter number
EKB3/
and number of attempts:
EKB3W/
Server 1: 68 att #
EWKB4
Server 2: 96 08 att #
Server 3: 96 09 att #
Value: att – number of attempts, range – [01... 255].
Example: 6809#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
Server 1: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP → OK → teSt
EKB2
PeRIOD → OK → tteessttpp → OK
Server 2: ... → SeRVeR2 IP → OK → teSt PeRIOD → OK → tteessttpp → OK
Server 3: ... → SeRVeR3 IP → OK → teSt PeRIOD → OK → tteessttpp → OK
Value: iiii – 4-digit installer code; tteessttpp – test period, range – [0... 65535] seconds.
Enter parameter 46 and number of attempts/parameter 96, parameter number
EKB3/
and number of attempts:
EKB3W/
Server 1: 46 tteessttpp #
EWKB4
Server 2: 96 10 tteessttpp #
Server 3: 96 11 tteessttpp #
Value: tteessttpp – test period, range – [0... 65535] seconds.
Example: 46120#
ElDES
Config-
uration
this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
Menu path:
Server 1: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP → OK → UNIt
EKB2
ID → OK → unid → OK
Server 2: ... → SeRVeR2 IP → OK → UNIt ID → OK → unid → OK
Server 3: ... → SeRVeR3 IP → OK → UNIt ID → OK → unid → OK
Value: iiii – 4-digit installer code; unid – 4-digit unit ID number.
Enter parameter 47 and unit ID number/parameter 96, parameter number and unit
EKB3/
ID number:
EKB3W/
Server 1: 47 unid #
EWKB4
Server 2: 96 14 unid #
Server 3: 96 15 unid #
Value: unid – 4-digit unit ID number.
Example: 472245#
