12.7. EWK1/EWK2 Wireless Keyfob

non-partitioned system:
EWK1/
to arm the system, press 1 of 4 keyfob buttons set to arm the system (by default, eWK1 –
EWK2
eWK2 button is pressed for arming, the system will proceed as follows:
• If ready (no violated zone/tamper), the system will arm.
• If unready, the system will not arm. In such case the user must restore all violated zones and tampers before arming the
system. Alternatively, the violated zones can be bypassed (see 14.7. Bypassing and activating Zones), disabled (see
14.9. Disabling and Enabling Zones) or a Force attribute enabled (resulting in partial arm; see 14.6. Zone attributes),
while the tampers can be disabled (see 16. taMPErS).
Partitioned system:
to arm the system, press 1 of 4 keyfob buttons with Partition Selection action assigned followed by a button with Arm the
System action assigned (by default, eWK1 –
will proceed as follows:
• If all partitions are disarmed ready (no violated zone/tamper), the system will arm them.
• If one or more partitions are disarmed unready (violated zone/tamper is present), the system will arm the ready par tition
(-s) and skip the unready one (-s).
• If a combination of armed and disarmed ready partitions is present, the system will arm the disarmed ready partitions and
skip the armed ones.
to disarm the system, press 1 of 4 keyfob buttons set to disarm the system (by default, eWK1 -
to verify if the system has been successfully armed, do not release the Arm the System keyfob button and wait for the 3 short
keyfob buzzer's beeps/indicator's flashes indicating the successfully carried out command. the long beep/flash indicates the
unsuccessful command.
When a certain keyfob's button is assigned to multiple partitions, the user will be able to arm/disarm the corresponding system
partition (-s) assigned to the button with Partition Selection action followed by a button with Arm the System/Disarm the
System action. For more details on how to set the keyfob partition, please refer to ELDES Configuration software's HeLP section.
notE:
Single eWK1/eWK2 keyfob button can be configured to carry out Partition Selection and Control Output/Output toggle/Output Pulse
actions. In such case the PGM output control action will be executed with a 3-second delay once the button is pressed and in case it is not
followed within a 3-second period by a button with Arm the System or Disarm the System action assigned.
52 52 EN
;eWK 2 -
36
Arm the
system
Arm the
system
38
Disarm
the
system
Disarm
the
system
). When eWK1/eWK2 button is pressed for arming, the system
37
39
ESIM384 Installation and Configuration Manual v1.1
;eWK 2 - ). When eWK1/
; eWK2 - ).
