16. taMPErS

the tamper circuit is a single closed loop such that a break in the loop at any point will cause a tamper alarm regardless of the system
status – armed or disarmed. During the tamper alarm, the system will activate the siren/bell and the keypad buzzer and send the SMS text
message to the listed user phone number. the system will cause tamper alarm under the following conditions:
• If the enclosure of a detection device, siren/bell, metal cabinet or keypad is opened, the physical tamper switch will be triggered. By
default, indicated as Tamper x in the SMS text message (x = tamper number). User is able to change tamper's name if he preffers to
(see 16.1. tamper names). Alternatively, the tamper switch can be connected to a zone resulting in zone alarm when tampered (see
15. ZonES).
• If the wireless signal is lost due to low signal level or low battery power on a certain wireless device (see 19.3. Wireless Signal Status
Monitoring).
By default, all tampers and tamper alarm notification by SMS text message is enabled. to disable/enable a certain tamper and/or tamper
alarm notification, please refer to the following configuration methods:
Disable/enable
tamper
View violated tampers
Disable tamper alarm
notification
Enable tamper alarm
notification
ESIM384 Installation and Configuration Manual v1.1
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
the system will automatically send an SMS text message, containing a violated tamper
SMS
name, to user phone number.
EKB2 Menu path:
EKB2
OK → uumm → OK → VIOLAteD tAMPeRS → OK → tAMPeR 1... 80
Value: uumm – 4-digit user/master code.
EKB3/ the illuminated indicator
EKB3W/ For more details on violated tamper indication, please refer to 29. InDICatIon of SYS tEM
EWKB4
faUltS.
Menu path:
User phone number:
EKB2
GSM USeR 1... 10 → OK → DISABLe → OK
SMS text message to all users simultaneously:
OK → DISABLe → OK
SMS delivery report:
Value: iiii – 4-digit installer code.
Enter parameter 25/21/55, event number, user phone number slot and parameter
EKB3/
status value:
EKB3W/
User phone number:
EWKB4
SMS text message to all users simultaneously:
SMS delivery report:
Value: up - user phone number slot, range - [01... 10].
Example: 2513030#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
User phone number:
EKB2
GSM USeR 1... 10 → OK → eNABLe → OK
SMS text message to all users simultaneously:
OK → eNABLe → OK
SMS delivery report:
Value: iiii – 4-digit installer code.
represents system fault presence including violated tam per.
OK → iiii → OK → SMS MeSSAGeS 1 → OK → tAMPeR ALARM → OK →
... → tAMPeR ALARM → OK → SMS tO ALL →
... → tAMPeR ALARM → OK → SMS RePORt → OK → DISABLe → OK
25 13 up 0 #
21 13 0 #
55 13 0 #
OK → iiii → OK → SMS MeSSAGeS 1 → OK → tAMPeR ALARM → OK →
... → tAMPeR ALARM → OK → SMS tO ALL →
... → tAMPeR ALARM → OK → SMS RePORt → OK → eNABLe → OK
